System And Components
480-7638 LINES GP-WATERS/N TXL5887-UP
Group No: 480-7638 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 8T9588 | 1 SEAL-O-RING | 1 | |
| 3381556 | 2 RETAINER | 2 | |
| 3441816 | 3 ELBOW | 1 | |
| 3498402 | 4 TUBE (INTEGRAL SEAL) | 1 | |
| 3559558 | 5 ELBOW | 1 | |
| 3888922 | 6 ELBOW | 1 | |
| 4456881 | 7 HOSE | 1 | |
| 5234273 | 8 CLAMP-BAND | 2 | |
| 4930357 | 9 TUBE AS | 1 | |
| 4930358 | 10 TUBE AS | 1 | |
| 0S0509 | 11 BOLT (3/8-16X0.75-IN) | 2 | |
| 0S1594 | 12 BOLT (3/8-16X1-IN) | 1 | |
| 1187214 | 13 SEAL-O-RING | 2 | |
| 1B9575 | 14 BOLT (5/16-18X1.56-IN) | 2 | |
| 1H5514 | 15 BOLT (5/16-18X1.625-IN) | 2 | |
| 2B2695 | 16 BOLT (5/16-18X0.875-IN) | 1 | |
| 3E4352 | 17 WASHER-HARD (8.8X20.5X2.5-MM THK) | 1 | |
| 4F7957 | 18 BOLT (1/4-20X0.875-IN) | 2 | |
| 5M2894 | 19 WASHER-HARD (10.2X18.5X2.5-MM THK) | 4 | |
| 5P0537 | 20 WASHER-HARD (7.2X14.5X2-MM THK) | 2 | |
| 7L6580 | 21 SEAL-O-RING | 2 | |
| 8S0023 | 22 CLIP (SLOT) | 2 | |
| 8S0024 | 23 CLIP (TAB) | 2 | |
| 9M1974 | 24 WASHER-HARD (8.8X16X2-MM THK) | 2 | |
| 9X6458 | 25 WASHER-HARD (10.2X22.5X3-MM THK) | 1 | |
| 4931489 | 26 BRACKET AS | 1 | |
| 4K9097 | NUT-WELD (5/16-18-THD) | 1 |
