Assembly
100%

480-7638 LINES GP-WATERS/N TXL5887-UP

Group No: 480-7638 · Commonality
Part NumberPart NameQty
8T95881 SEAL-O-RING1
33815562 RETAINER2
34418163 ELBOW1
34984024 TUBE (INTEGRAL SEAL)1
35595585 ELBOW1
38889226 ELBOW1
57271747 TUBE AS1
0S050911 BOLT (3/8-16X0.75-IN)2
0S159412 BOLT (3/8-16X1-IN)1
118721413 SEAL-O-RING2
1B957514 BOLT (5/16-18X1.56-IN)2
1H551415 BOLT (5/16-18X1.625-IN)2
2B269516 BOLT (5/16-18X0.875-IN)1
3E435217 WASHER-HARD (8.8X20.5X2.5-MM THK)1
4F795718 BOLT (1/4-20X0.875-IN)2
5M289419 WASHER-HARD (10.2X18.5X2.5-MM THK)4
5P053720 WASHER-HARD (7.2X14.5X2-MM THK)2
7L658021 SEAL-O-RING2
8S002322 CLIP (SLOT)2
8S002423 CLIP (TAB)2
9M197424 WASHER-HARD (8.8X16X2-MM THK)2
9X645825 WASHER-HARD (10.2X22.5X3-MM THK)1
493148926 BRACKET AS1
4K9097NUT-WELD (5/16-18-THD)1
