System And Components
430-3228 RADIATOR GPS/N T4P1-UP
Group No: 430-3228 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2705131 | 1 SHIM (1-MM THK) | 2 | |
| 3324567 | 2 CORE AS-RADIATOR | 1 | |
| 3363488 | 3 SUPPORT AS (BOTTOM) | 1 | |
| 8T3597 | NUT-WELD (M12X1.75-THD) | 1 | |
| 3390577 | 4 MOUNTING AS (RH) | 1 | |
| 3390578 | 5 MOUNTING AS (LH) | 1 | |
| 3398067 | 6 FRAME AS (RH) | 1 | |
| 3398071 | 7 FRAME AS (LH) | 1 | |
| 3398078 | 8 MOUNT AS | 1 | |
| 3772050 | 9 SUPPORT AS-TOP | 1 | |
| 7X7729 | 10 WASHER (11X25X3-MM THK) | 36 | |
| 8T4136 | 11 BOLT (M10X1.5X25-MM) | 8 | |
| 8T4195 | 12 BOLT (M10X1.5X30-MM) | 20 | |
| 8T4196 | 13 BOLT (M10X1.5X35-MM) | 8 | |
| 3509386 | KIT-SEAL | 1 |
