System And Components
291-8995 SHROUD GP-RADIATORS/N T4P1-UP
Group No: 291-8995 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1766279 | 1 BUSHING-RUBBER | 1 | |
| 1766404 | 2 BUSHING-RUBBER | 1 | |
| 2096148 | 3 COVER | 1 | |
| 2096149 | 4 PLATE | 1 | |
| 2097533 | 5 COVER | 1 | |
| 2097534 | 6 PLATE | 2 | |
| 2097535 | 7 PLATE | 2 | |
| 2127961 | 8 PLATE | 1 | |
| 3518199 | 9 DUCT AS | 1 | |
| 3529305 | 10 NUT-SPRING | 2 | |
| 3533434 | 11 BRACKET | 2 | |
| 3580725 | 12 PLATE AS | 2 | |
| 8T3612 | NUT-WELD (M8X1.25-THD) | 2 | |
| 5C7261 | 13 NUT (M8X1.25-THD) | 4 | |
| 5P4116 | 14 WASHER-HARD (8.8X20.5X2-MM THK) | 22 | |
| 7X2537 | 15 BOLT (M8X1.25X35-MM) | 10 | |
| 7X7729 | 16 WASHER (11X25X3-MM THK) | 6 | |
| 7Y5456 | 17 GROMMET | 1 | |
| 8T4195 | 18 BOLT (M10X1.5X30-MM) | 6 | |
| 8T4197 | 19 BOLT (M8X1.25X40-MM) | 1 | |
| 8T4908 | 20 BOLT (M8X1.25X25-MM) | 4 | |
| 8T7547 | 21 BOLT (M8X1.25X30-MM) | 7 | |
| 3T0852 | 22 LOCKNUT (M8X1.25-THD) | 4 |
