System And Components
464-3469 SHROUD GP-RADIATORS/N T4P1-UP
Group No: 464-3469 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1766279 | 1 BUSHING-RUBBER | 1 | |
| 1766404 | 2 BUSHING-RUBBER | 1 | |
| 2096148 | 3 COVER | 1 | |
| 2097533 | 4 COVER | 1 | |
| 2097534 | 5 PLATE | 2 | |
| 2097535 | 6 PLATE | 2 | |
| 2127961 | 7 PLATE | 1 | |
| 3529305 | 8 NUT-SPRING | 2 | |
| 3533434 | 9 BRACKET | 1 | |
| 3580725 | 10 PLATE AS | 2 | |
| 8T3612 | NUT-WELD (M8X1.25-THD) | 1 | |
| 3821411 | 11 PLATE | 1 | |
| 3971579 | 12 BRACKET | 1 | |
| 4187666 | 13 PLATE-RETAINING | 1 | |
| 4643357 | 14 DUCT AS | 1 | |
| 4649019 | 15 PLUG-BUTTON | 2 | |
| 4649020 | 16 PLUG-BUTTON | 1 | |
| 3T0852 | 17 LOCKNUT (M8X1.25-THD) | 4 | |
| 5C7261 | 18 NUT (M8X1.25-THD) | 4 | |
| 5P4116 | 19 WASHER-HARD (8.8X20.5X2-MM THK) | 11 | |
| 7X0579 | 20 WASHER-HARD (8.8X25.5X2-MM THK) | 11 | |
| 7X2537 | 21 BOLT (M8X1.25X35-MM) | 10 | |
| 7X7729 | 22 WASHER (11X25X3-MM THK) | 6 | |
| 7Y5456 | 23 GROMMET | 1 | |
| 8T4195 | 24 BOLT (M10X1.5X30-MM) | 6 | |
| 8T4197 | 25 BOLT (M8X1.25X40-MM) | 1 | |
| 8T4908 | 26 BOLT (M8X1.25X25-MM) | 4 | |
| 8T7547 | 27 BOLT (M8X1.25X30-MM) | 7 |
