340-6038 LINES GP-EXHAUSTS/N T4P1-UP

Group No: 340-6038 · Commonality
Part NumberPart NameQty
4B52721 WASHER (12.7X31.7X2-MM THK)3
6U52192 U-CLAMP AS3
6V8801NUT (3/8-16-THD)2
8T4896WASHER-HARD (10.2X18.5X2.5-MM THK)2
8C56083 SPACER (6.5X9.5X25.4-MM THK)3
8T64314 ROD END2
9X98965 MOUNT (ISOLATION)6
14204856 NUT (M10X1.5-THD)2
17590797 ROD-LINK1
17682348 CLAMP1
19033819 SHIELD-EXHAUST1
190534110 CLAMP1
197483411 SEAL1
197483512 PLATE-RETAINER1
202183813 CLAMP-V BAND2
469609414 PLATE1
211232615 BOSS3
211463516 PIPE-EXHAUST1
226265917 WASHER-BELLEVILLE (13X29X3-MM THK)2
249284418 WASHER (12.7X31.7X1-MM THK)3
469609219 PLATE AS1
1754782BOSS1
264622620 PLATE-MOUNTING1
264747721 PLATE-MOUNTING1
264881622 SPACER (10.5X16X8.5-MM THK)4
287031023 SPACER (11X20X70-MM THK)1
376640224 PIPE1
334923225 BRACKET1
353122126 PIPE GP-EXHAUST1
353122327 SUPPORT AS1
361989528 PIPE AS1
5C289029 NUT (M6X1-THD)3
6V768730 LOCKNUT (M12X1.75-THD)1
6V774431 LOCKNUT (M10X1.5-THD)1
6V880132 NUT (3/8-16-THD)6
7X255033 BOLT (M12X1.75X110-MM)1
7X772934 WASHER (11X25X3-MM THK)4
8C845135 BOLT (M6X1X40-MM)3
8T412136 WASHER-HARD (11X21X2.5-MM THK)7
8T413337 NUT (M10X1.5-THD)4
8T418438 BOLT (M12X1.75X45-MM)6
8T418539 BOLT (M10X1.5X50-MM)2
8T418941 BOLT (M8X1.25X20-MM)6
8T418242 BOLT (M10X1.5X45-MM)4
8T419943 BOLT (M8X1.25X12-MM)4
8T422344 WASHER-HARD (13.5X25.5X3-MM THK)8
8T422445 WASHER-HARD (8.8X16X2-MM THK)12
8T668546 BOLT (M10X1.5X110-MM)1
8T754747 BOLT (M8X1.25X30-MM)2
9X616548 WASHER (6.5X22X2.5-MM THK)6
198477749 WASHER-HARD (11X25X10-MM THK)2
380880350 NUT-INSERT (M10X1.5-THD)2
