341-3682 BATTERY & WIRING GPS/N T4P1-UP

Group No: 341-3682 · Commonality

Part Number	Part Name	Qty
2G8767	1 WASHER (10.5X60X3-MM THK)	8
3S2093	2 STRAP-CABLE	21
6G2256	3 CLAMP	8
6U2703	4 BRACKET-ANGLE	1
7N0718	5 SWITCH GP-DISCONNECT	1
8S2634	6 COVER AS	1
9G2758	7 LOCKOUT-SWITCH	1
9R4600	8 CLIP	1
1245814	9 BLOCK GP-JUNCTION (BATTERY)(LOWER)	1
1535700	10 BATTERY AS (12-VOLT, 1125-CCA)(MAINTENANCE FREE)	2
1763393	12 STUD	2
3379078	13 SWITCH GP-MAGNETIC (24-VOLT TO 32-VOLT)(SECONDARY STEERING RELAY)	1
1893158	14 SUPPRESSOR-ARC	1
2060154	15 CABLE AS	1
3S6049	TERMINAL AS-BATTERY (POSITIVE)	1
3S6050	TERMINAL AS-BATTERY (NEGATIVE)	1
1M6119	BOLT (5/16-18X1.375-IN)	1
1M6120	NUT (5/16-18-THD)	1
1598049	CABLE (00-GA, RED)(43-CM)
7N5274	COVER AS-TERMINAL (BLACK)	1
8N1725	COVER AS-TERMINAL (RED)	1
8L8413	STRAP-CABLE (WHITE)	1
2532673	16 SWITCH GP-PRESSURE (HYDRAULIC OIL FILTER)	1
2532673	16A SWITCH GP-PRESSURE (STEERING OIL FILTER)	1
1028802	KIT-RECEPTACLE (2-PIN)	1
8T8729	PIN-CONNECTOR (16-GA TO 20-GA)	2
9X1813	SLEEVE (14-CM)
3J1907	SEAL-O-RING	1
5F9144	SEAL-O-RING	1
2566453	17 SENSOR-TEMPERATURE (2-PIN)(STEERING OIL)	1
2566453	17A SENSOR-TEMPERATURE (2-PIN)(HYDRAULIC OIL)	1
3369298	18 CABLE AS	1
1598050	CABLE (00-GA, BLACK)(108-CM)
7N5274	COVER AS-TERMINAL (BLACK)	1
8L8413	STRAP-CABLE (WHITE)	1
0375197	BOOT	1
2352678	TERMINAL-RING	1
3S6050	TERMINAL AS-BATTERY (NEGATIVE)	1
1M6119	BOLT (5/16-18X1.375-IN)	1
1M6120	NUT (5/16-18-THD)	1
3369299	19 CABLE AS	1
1S7251	TERMINAL-CABLE (00-GA, 1/2-IN SCREW)	1
1598050	CABLE (00-GA, BLACK)(65-CM)
2352678	TERMINAL-RING	1
3369300	20 CABLE AS	1
1598049	CABLE (00-GA, RED)(105-CM)
8N0869	COVER-TERMINAL (RED)	1
8N1725	COVER AS-TERMINAL (RED)	1
8L8413	STRAP-CABLE (WHITE)	1
3S6049	TERMINAL AS-BATTERY (POSITIVE)	1
1M6119	BOLT (5/16-18X1.375-IN)	1
1M6120	NUT (5/16-18-THD)	1
2352677	TERMINAL-RING	1
3369301	21 CABLE AS	1
1598050	CABLE (00-GA, BLACK)(133-CM)
1P0810	TAPE-ELECTRICAL
2352678	TERMINAL-RING	2
3369302	22 CABLE AS	1
1598049	CABLE (00-GA, RED)(228-CM)
8N0869	COVER-TERMINAL (RED)	1
1939141	COVER-TERMINAL	1
2352677	TERMINAL-RING	1
2352678	TERMINAL-RING	1
3369303	23 CABLE AS	1
1598050	CABLE (00-GA, BLACK)(128-CM)
2352678	TERMINAL-RING	2
3369304	24 CABLE AS	1
1598050	CABLE (00-GA, BLACK)(35-CM)
0375197	BOOT	2
2352678	TERMINAL-RING	2
3369305	25 CABLE AS	1
1598049	CABLE (00-GA, RED)(66-CM)
8N0869	COVER-TERMINAL (RED)	1
2352677	TERMINAL-RING	1
3373986	26 PLATE AS	1
3919588	27 PLATE AS	1
3389969	28 CABLE AS	1
6V2722	TUBE-HEAT SHRINK (25.4-MM DIA)(0.1-M)
1M4986	TERMINAL-RING (0-GA, 1/2-IN SCREW)	1
8N0869	COVER-TERMINAL (RED)	1
0301709	TERMINAL-RING (0-GA, 1/4-IN SCREW)	1
3919599	29 PLATE AS	1
3429671	30 RECEPTACLE AS-AUXILIARY START	1
3569741	31 CABLE AS	1
1598049	CABLE (00-GA, RED)(81-CM)
6V2722	TUBE-HEAT SHRINK (25.4-MM DIA)(0.1-M)
8N0869	COVER-TERMINAL (RED)	1
2352677	TERMINAL-RING	1
2352678	TERMINAL-RING	1
3570111	32 PLATE	2
3589368	33 PLATE AS	1
8T3490	NUT-WELD (M10X1.5-THD)	2
2636342	34 CLIP	16
3J1907	35 SEAL-O-RING	2
3K0360	36 SEAL-O-RING	2
3491209	37 CLIP	7
4P7428	38 CLIP (LADDER)	2
4P7581	39 CLIP (LADDER)	4
4P8134	40 CLIP (LADDER)	1
5F9144	41 SEAL-O-RING	2
5G6505	42 WASHER (25X38X14-MM THK)	3
7X7729	43 WASHER (11X25X3-MM THK)	4
8P8540	44 GROMMET	1
8T4121	45 WASHER-HARD (11X21X2.5-MM THK)	29
8T4133	46 NUT (M10X1.5-THD)	6
8T4136	47 BOLT (M10X1.5X25-MM)	26
8T4137	48 BOLT (M10X1.5X20-MM)	3
8T4139	49 BOLT (M12X1.75X30-MM)	2
5C9553	50 BOLT (M6X1X16-MM)	4
8T4185	51 BOLT (M10X1.5X50-MM)	1
8T4195	52 BOLT (M10X1.5X30-MM)	3
8T4223	53 WASHER-HARD (13.5X25.5X3-MM THK)	2
8T4224	54 WASHER-HARD (8.8X16X2-MM THK)	5
8T4908	55 BOLT (M8X1.25X25-MM)	4
9X8256	56 WASHER (6.6X12X2-MM THK)	4
8T4189	57 BOLT (M8X1.25X20-MM)	1
