System And Components
225-5075 LAMP GP-FLOODS/N T4P1-UP
Group No: 225-5075 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3519918 | 1 LAMP-HALOGEN (24-VOLT, 70-WATT)(FLOOD) | 1 | |
| 8T6912 | 2 BOLT (M8X1.25X50-MM) | 1 | |
| 5C7261 | 3 NUT (M8X1.25-THD) | 1 | |
| 8T4224 | 4 WASHER-HARD (8.8X16X2-MM THK) | 2 | |
| 9X4244 | 5 SCREW-SPECIAL (M4X1.79X25-MM) | 2 | |
| 2026611 | 6 LENS AS (FLOODLIGHT) | 1 | |
| 1754292 | 7 BODY AS (SHOCK ABSORBER) | 1 | |
| 1647556 | 8 BRACKET (LAMP RETAINING) | 1 | |
| 1754291 | 9 BRACKET AS | 1 | |
| 1028802 | 10 KIT-RECEPTACLE (2-PIN) | 1 | |
| 8T8729 | 11 PIN-CONNECTOR (16-GA TO 20-GA) | 2 |
