Assembly
100%

337-6317 PANEL GP-CIRCUIT BREAKERS/N T4P1-UP

Group No: 337-6317 · Commonality
Part NumberPart NameQty
3E51691 GUARD-SWITCH1
3S20932 STRAP-CABLE9
7U48913 SCREW (10-32X1-IN)6
7V92754 STRAP2
17122055 CIRCUIT BREAKER AS (40-AMPERE)(MAIN)2
21649706 CIRCUIT BREAKER AS (120-AMPERE)(MAIN)1
1H3244LOCKWASHER2
4E5724WASHER (7X12X1-MM THK)2
8T0122NUT-FULL (1/4-28-THD)2
39809407 SWITCH GP-MAGNETIC (24-VOLT)(START RELAY)1
28836878 CIRCUIT BREAKER AS (20-AMPERE)(FAN)1
6V8378NUT (10-32-THD)2
8F1434LOCKWASHER2
8T0328WASHER-HARD (5.5X10X1-MM THK)2
29787529 SWITCH GP-TOGGLE (ENGINE SHUTOFF)1
336281610 HARNESS AS-PANEL (CIRCUIT BREAKER)1
343797911 PLATE-IDENTIFICATION (DISCONNECT)1
353223412 WIRE AS (10-GA, RED)1
353223513 WIRE AS1
353686414 PLATE-FILM1
354123615 CLIP1
139472416 CIRCUIT BREAKER AS (30-AMPERE)(ENGINE ECM)1
6V8378NUT (10-32-THD)2
8F1434LOCKWASHER2
8T0328WASHER-HARD (5.5X10X1-MM THK)2
4P813417 CLIP (LADDER)3
6D424618 CLIP (LOOP)1
7U489219 SCREW (8-32X0.75-IN)4
8T412120 WASHER-HARD (11X21X2.5-MM THK)7
8T413321 NUT (M10X1.5-THD)3
8T413622 BOLT (M10X1.5X25-MM)2
8T413723 BOLT (M10X1.5X20-MM)2
8T417124 BOLT (M6X1X12-MM)2
9X825625 WASHER (6.6X12X2-MM THK)2
