System And Components
343-8057 SENSOR GP-ENGINES/N TXL1-UP; L4X1-UP
Group No: 343-8057 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3S2093 | 1 STRAP-CABLE | 4 | |
| 6J4608 | 2 BOLT-SOCKET HEAD (5/16-18X0.625-IN) | 2 | |
| 2345012 | 3 SENSOR GP-TEMPERATURE (COOLANT) | 1 | |
| 2345013 | 4 SENSOR GP-TEMPERATURE (AIR INLET) | 1 | |
| 2893891 | 5 CLIP | 1 | |
| 2935535 | 6 SENSOR GP-PRESSURE (ENGINE OIL) | 1 | |
| 2946119 | 7 SENSOR GP-PRESSURE (CRANKCASE BREATHER) | 1 | |
| 3009805 | 8 SENSOR GP-SPEED (ENGINE SPEED) | 1 | |
| 3009806 | 9 SENSOR GP-SPEED (SECONDARY, TIMING) | 1 | |
| 3311134 | 10 SENSOR GP-PRESSURE (ATMOSPHERIC) | 1 | |
| 3311135 | 11 SENSOR GP-PRESSURE (INTAKE AIR MANIFOLD) | 1 | |
| 3320296 | 12 SENSOR GP-PRESSURE (NRS ABSOLUTE) | 1 | |
| 3398822 | 13 SENSOR AS-TEMPERATURE (NOX REDUCTION SYSTEM) | 1 | |
| 3445734 | 14 HARNESS AS-SENSOR | 1 | |
| 3477104 | 15 BRACKET AS | 1 | |
| 3668024 | 16 BRACKET | 1 | |
| 3717163 | 17 CONNECTOR AS | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 3717162 | ADAPTER-ELBOW | 1 | |
| 3824384 | 18 SENSOR GP-PRESSURE (NRS DIFFERENTIAL) | 1 | |
| 0S1617 | 19 BOLT (5/16-18X0.75-IN) | 2 | |
| 1378101 | 20 SEAL-O-RING | 2 | |
| 2H3755 | 21 BOLT (5/16-18X0.43-IN) | 2 | |
| 3535112 | 22 ADAPTER AS | 1 | |
| 9X0262 | ADAPTER | 1 | |
| 2147566 | SEAL-O-RING | 2 | |
| 3B1915 | 23 BOLT (3/8-16X1.375-IN) | 2 | |
| 4P7581 | 24 CLIP (LADDER) | 1 | |
| 4P8134 | 25 CLIP (LADDER) | 1 | |
| 5M2894 | 26 WASHER-HARD (10.2X18.5X2.5-MM THK) | 2 | |
| 6V5217 | 27 BOLT (M8X1.25X20-MM) | 1 | |
| 8T0267 | 28 BOLT-SOCKET HEAD (M6X1X12-MM) | 2 | |
| 9M1974 | 29 WASHER-HARD (8.8X16X2-MM THK) | 7 | |
| 9X8267 | 30 WASHER (6.6X12X2-MM THK) | 2 |
