System And Components
343-8057 SENSOR GP-ENGINES/N TXL1-UP
Group No: 343-8057 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3S2093 | 1 STRAP-CABLE | 5 | |
| 2345012 | 2 SENSOR GP-TEMPERATURE (COOLANT) | 1 | |
| 2345013 | 3 SENSOR GP-TEMPERATURE (AIR INLET) | 1 | |
| 2893891 | 4 CLIP | 1 | |
| 2935535 | 5 SENSOR GP-PRESSURE (ENGINE OIL) | 1 | |
| 2946119 | 6 SENSOR GP-PRESSURE (CRANKCASE BREATHER) | 1 | |
| 3009805 | 7 SENSOR GP-SPEED (CRANKSHAFT) | 1 | |
| 3009806 | 8 SENSOR GP-SPEED (CAMSHAFT) | 1 | |
| 3311134 | 9 SENSOR GP-PRESSURE (ATMOSPHERIC) | 1 | |
| 3311135 | 10 SENSOR GP-PRESSURE (INTAKE AIR MANIFOLD) | 1 | |
| 3320296 | 11 SENSOR GP-PRESSURE (NRS ABSOLUTE) | 1 | |
| 4743231 | 12 SENSOR AS-TEMPERATURE (2-PIN)(NOX REDUCTION SYSTEM) | 1 | |
| 2818802 | RECEPTACLE AS-CONNECTOR (2-PIN) | 1 | |
| 5713086 | 13 HARNESS AS-SENSOR (CHARGE AIR COOLER) | 1 | |
| 3477104 | 14 BRACKET AS | 1 | |
| 3668024 | 15 BRACKET | 1 | |
| 3717163 | 16 CONNECTOR AS | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 3717162 | ADAPTER-ELBOW | 1 | |
| 3851173 | 17 SENSOR GP-PRESSURE (NRS DIFFERENTIAL) | 1 | |
| 4218565 | 18 BRACKET | 1 | |
| 0S1617 | 19 BOLT (5/16-18X0.75-IN) | 2 | |
| 0S1618 | 20 BOLT (5/16-18X1-IN) | 2 | |
| 1378101 | 21 SEAL-O-RING | 2 | |
| 2H3755 | 22 BOLT (5/16-18X0.43-IN) | 2 | |
| 3535112 | 23 ADAPTER AS | 1 | |
| 9X0262 | ADAPTER | 1 | |
| 2147566 | SEAL-O-RING | 2 | |
| 3B1915 | 24 BOLT (3/8-16X1.375-IN) | 2 | |
| 4P7581 | 25 CLIP (LADDER) | 1 | |
| 4P8134 | 26 CLIP (LADDER) | 1 | |
| 5M2894 | 27 WASHER-HARD (10.2X18.5X2.5-MM THK) | 2 | |
| 6V5217 | 28 BOLT (M8X1.25X20-MM) | 1 | |
| 8T0267 | 29 BOLT-SOCKET HEAD (M6X1X12-MM) | 2 | |
| 9M1974 | 30 WASHER-HARD (8.8X16X2-MM THK) | 5 | |
| 9X8267 | 31 WASHER (6.6X12X2-MM THK) | 2 |
