System And Components
358-6986 WIRING GP-CABS/N T4P1-UP
Group No: 358-6986 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3E5239 | 1 RELAY AS (24-VOLT)(WIPER) | 1 | |
| 3E6328 | 2 ALARM GP (24-VOLT)(CATERPILLAR MONITORING SYSTEM) | 1 | |
| 6I1418 | 3 SPACER (8.2X12.7X28.7-MM THK) | 8 | |
| 7G1060 | 4 STRAP AS-GROUND (CHASSIS) | 1 | |
| 8E1118 | 5 ANTENNA AS (RADIO) | 1 | |
| 8T9655 | 6 MOUNT-ISOLATION (POWER TRAIN) | 16 | |
| 9D4068 | 7 SWITCH-PUSH BUTTON (DOME LIGHT) | 1 | |
| 9U8263 | 8 COVER | 1 | |
| 9X2185 | 9 SCREW (8-15X0.44-IN) | 4 | |
| 1076032 | 10 LAMP AS-DOME (24-VOLT)(CAB) | 1 | |
| 2591286 | LAMP (24-VOLT, 10-WATT) | 1 | |
| 1098981 | 11 CABLE AS-COAXIAL | 1 | |
| 1165710 | 12 GROMMET | 1 | |
| 1172311 | 13 SOCKET-AUXILIARY POWER (12-VOLT) | 1 | |
| 1246046 | 14 SPEAKER AS-RADIO | 2 | |
| 1286157 | 15 PLATE | 2 | |
| 1636088 | 16 MODULE AS (INTERMITTENT WIPER) | 1 | |
| 1028803 | KIT-RECEPTACLE (3-PIN) | 1 | |
| 8T8729 | PIN-CONNECTOR (16-GA TO 20-GA) | 3 | |
| 1648473 | 17 LOUVER AS-VENT | 2 | |
| 1893744 | 18 SEAL | 1 | |
| 1959223 | 19 SCREW-PAN HEAD (10-14X0.63-IN) | 4 | |
| 2414505 | 20 PLUG | 8 | |
| 2418368 | 21 SWITCH GP-MAGNETIC (24-VOLT)(MAIN POWER RELAY) | 1 | |
| 2552752 | 22 SWITCH GP-START (IGNITION)(KEY) | 1 | |
| 2600162 | 23 LAMP GP-FLOOD (24-VOLT) | 1 | |
| 2675243 | 24 PANEL AS | 1 | |
| 2717312 | KNOB | 1 | |
| 2857415 | KNOB | 1 | |
| 2712818 | 25 SWITCH AS-ROCKER (HEADLIGHTS) | 1 | |
| 2712825 | 26 SWITCH AS-ROCKER (AIR CONDITIONER) | 1 | |
| 2712826 | 27 SWITCH AS-ROCKER (WORK LIGHT) | 1 | |
| 2712827 | 28 SWITCH AS-ROCKER (REAR WASHER, WIPER) | 1 | |
| 2712828 | 29 SWITCH AS-ROCKER (HAZARD) | 1 | |
| 2712830 | 30 SWITCH AS-ROCKER (SECONDARY STEERING) | 1 | |
| 2719408 | 31 SCREW-TRUSS HEAD (M5X0.8X10-MM) | 4 | |
| 2739761 | 32 BRACKET | 1 | |
| 2831433 | 33 PLATE-MOUNTING | 1 | |
| 2881401 | 34 BRACKET | 1 | |
| 2999240 | 35 SWITCH AS-MULTIFUNCTION (HD LIGHT, TURN SIG, WDO WIPER)(LH) | 1 | |
| 8T8729 | PIN-CONNECTOR (16-GA TO 20-GA) | 12 | |
| 1743091 | KIT-RECEPTACLE (12-PIN) | 1 | |
| 2999241 | 36 SWITCH AS-LEVER (BRAKE RETARDER)(RH) | 1 | |
| 8T8729 | PIN-CONNECTOR (16-GA TO 20-GA) | 4 | |
| 8T8737 | PLUG-SEAL | 2 | |
| 1519275 | KIT-RECEPTACLE (6-PIN) | 1 | |
| 3026392 | 37 PLUG | 2 | |
| 3196827 | 38 HARNESS AS-WIRING (CAMERA) | 1 | |
| 3209715 | 39 CABLE AS (CAMERA) | 1 | |
| 3292477 | 40 PLATE AS | 1 | |
| 5C9855 | BOSS (M8X1.25X19-MM) | 8 | |
| 3312886 | 41 SWITCH AS-ROCKER (ENGINE RATING) | 1 | |
| 3312887 | 42 SWITCH AS-ROCKER (HEADLIGHT DIMMER) | 1 | |
| 1117899 | GASKET | 1 | |
| 3327644 | 43 MODULE GP-DISPLAY (INSTRUMENT CLUSTER) | 1 | |
| 3648277 | FILM-IDENTIFICATION (CAT) | 1 | |
| 3329701 | 44 HARNESS AS-WINDOW WIPER | 1 | |
| 3329704 | 45 HARNESS AS-CAB (GEARSHIFT) | 1 | |
| 3329706 | 46 HARNESS AS-CAB | 1 | |
| 3329707 | 47 HARNESS AS-CAB (ROOF) | 1 | |
| 3347785 | 48 SWITCH AS-ROCKER (HOOD RELEASE) | 1 | |
| 1117899 | GASKET | 1 | |
| 3366687 | 49 CAP-PROTECTIVE (FEMALE) | 1 | |
| 3368940 | 50 DISPLAY GP-MONITOR (CMPD) | 1 | |
| 3407161 | 51 CONVERTER-POWER (24-VOLT TO 12-VOLT) | 1 | |
| 3407389 | 52 PANEL AS-INSTRUMENT | 1 | |
| 4662495 | 53 BEZEL | 1 | |
| 3442592 | 54 PLATE AS | 1 | |
| 6V9632 | NUT-WELD (M6X1-THD) | 8 | |
| 7T1099 | LINK | 3 | |
| 8C8499 | BOSS-WELD (M10X1.5X50-MM) | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 2 | |
| 3468101 | 55 HARNESS AS-TRANSMISSION (TRANSMISSION OUTPUT SPEED) | 1 | |
| 8T8729 | PIN-CONNECTOR (16-GA TO 20-GA) | 8 | |
| 2450168 | RECEPTACLE AS-CONNECTOR (8-PIN) | 1 | |
| 3469671 | 56 HARNESS AS-WIRING (SEAT) | 1 | |
| 3479507 | 57 BEZEL-RADIO | 1 | |
| 3540738 | 58 PLATE AS | 1 | |
| 6V9632 | NUT-WELD (M6X1-THD) | 6 | |
| 7T1099 | LINK | 1 | |
| 3547732 | 59 WIRE AS | 1 | |
| 3547735 | 60 HARNESS AS-CAB (FUSE BLOCK) | 1 | |
| 3588802 | 61 INSULATION | 1 | |
| 3637677 | 62 DOOR GP-ACCESS (FUSE PANEL) | 1 | |
| 3H0240 | WASHER (5X9.7X0.8-MM THK) | 7 | |
| 9M5733 | RIVET-POP | 7 | |
| 3024764 | LATCH AS | 1 | |
| 3442588 | HINGE AS | 1 | |
| 3670794 | 63 PLUG | 2 | |
| 3675213 | 64 SWITCH AS-ROCKER (24-VOLT) | 1 | |
| 3792433 | 65 HARNESS AS-PANEL | 1 | |
| 3792434 | 66 HARNESS AS-CAB | 1 | |
| 1146658 | 67 WASHER (6.5X17X1-MM THK) | 2 | |
| 1042091 | 68 SCREW-FLAT HEAD (6-20X0.5-IN) | 8 | |
| 1240174 | 69 CLIP (LOOP) | 1 | |
| 1305300 | 70 CLIP | 2 | |
| 1616987 | 71 WASHER-HARD (5.2X16X1.5-MM THK) | 2 | |
| 1748131 | 72 SCREW-TRUSS HEAD (M4X0.7X12-MM) | 4 | |
| 2137315 | 73 SCREW-TRUSS HEAD (M4X0.7X25-MM) | 6 | |
| 2986434 | 74 SCREW (M5X0.8X12-MM) | 2 | |
| 3045687 | 75 CONTROL GP-UNPROGRAMMED (ELECTRONIC) | 2 | |
| 3E8020 | 76 SCREW-TRUSS HEAD (M6X1X25-MM) | 6 | |
| 3S2093 | 77 STRAP-CABLE | 51 | |
| 3S9557 | 78 SCREW-PAN HEAD (4-40X0.5-IN) | 8 | |
| 4P7581 | 79 CLIP (LADDER) | 7 | |
| 4P8134 | 80 CLIP (LADDER) | 2 | |
| 5C9553 | 81 BOLT (M6X1X16-MM) | 1 | |
| 5P4116 | 82 WASHER-HARD (8.8X20.5X2-MM THK) | 10 | |
| 5P8525 | 83 GROMMET | 1 | |
| 5P9297 | 84 CLIP (LOOP) | 2 | |
| 6D4244 | 85 CLIP (LOOP) | 1 | |
| 6V5839 | 86 WASHER (11X21X2.5-MM THK) | 1 | |
| 7I2272 | 87 BOLT (M5X0.8X12-MM) | 8 | |
| 7K1181 | 88 STRAP-CABLE | 18 | |
| 7X0818 | 89 BOLT (M8X1.25X45-MM) | 8 | |
| 7X7729 | 91 WASHER (11X25X3-MM THK) | 3 | |
| 8C8451 | 92 BOLT (M6X1X40-MM) | 2 | |
| 8D6946 | 93 FLASHER AS (24-VOLT)(TURN SIGNAL) | 1 | |
| 8M2770 | 94 CLIP (LOOP) | 2 | |
| 8T0289 | 95 BOLT (M5X0.8X20-MM) | 2 | |
| 8T0328 | 96 WASHER-HARD (5.5X10X1-MM THK) | 8 | |
| 8T4121 | 97 WASHER-HARD (11X21X2.5-MM THK) | 16 | |
| 8T4133 | 98 NUT (M10X1.5-THD) | 1 | |
| 8T4137 | 99 BOLT (M10X1.5X20-MM) | 17 | |
| 8T4138 | 100 BOLT (M6X1X20-MM) | 4 | |
| 8T4191 | 101 BOLT (M10X1.5X16-MM) | 3 | |
| 8T4205 | 102 WASHER-HARD (7.2X14.5X2-MM THK) | 6 | |
| 8T4970 | 103 BOLT (M6X1X14-MM) | 2 | |
| 9W0335 | 104 LIGHTER AS-CIGAR (24-VOLT) | 1 | |
| 9X1046 | 105 SCREW (M4X0.7X18-MM) | 16 | |
| 9X2045 | 106 SCREW-TRUSS HEAD (M6X1X20-MM) | 8 | |
| 9X8256 | 107 WASHER (6.6X12X2-MM THK) | 3 |
