System And Components
363-0622 WIRING GP-CEMS/N T4P1-UP
Group No: 363-0622 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1439607 | 1 STRAP-CABLE | 7 | |
| 2674211 | 2 SPACER (8.8X16X15-MM THK) | 1 | |
| 2901993 | 3 STRAP-CABLE | 66 | |
| 2956238 | 4 WIRE AS-IGNITION | 1 | |
| 3150225 | 5 CLAMP-WIRE | 1 | |
| 3349644 | 6 SLEEVE | 4 | |
| 3327558 | SLEEVE (15-CM) | ||
| 3349645 | 7 SLEEVE AS | 10 | |
| 3327558 | SLEEVE (8-CM) | ||
| 3414176 | 8 SENSOR GP-TEMPERATURE (DUAL SENSOR- DPF, FLAME DETECT) | 1 | |
| 3429070 | 9 RECEPTACLE AS (AFTERTREATMENT IDENTIFICATION) | 1 | |
| 5P5677 | WIRE (18-GA, BLACK)(0.2-M) | ||
| 8T8729 | PIN-CONNECTOR (16-GA TO 20-GA) | 6 | |
| 2818812 | RECEPTACLE AS-CONNECTOR (6-PIN) | 1 | |
| 3442769 | 10 STUD | 2 | |
| 3445516 | 11 PLATE | 1 | |
| 3445518 | 12 PLATE | 1 | |
| 3448949 | 13 SLEEVE | 1 | |
| 3263570 | INSULATION (18-CM) | ||
| 3448950 | 14 SLEEVE | 1 | |
| 3249708 | INSULATION (8-CM) | ||
| 3524756 | 15 HARNESS AS-CEM (NOZZLE HEATER) | 1 | |
| 3558808 | 16 SLEEVE | 2 | |
| 3327558 | SLEEVE (9-CM) | ||
| 3630614 | 17 PLATE | 1 | |
| 3630625 | 18 HARNESS AS-CEM | 1 | |
| 3E6446 | CAP AS-CONNECTOR | 1 | |
| 1106844 | SEAL | 1 | |
| 1936910 | INSULATION (296-CM) | ||
| 3249702 | INSULATION (219-CM) | ||
| 9X3401 | PIN-CONNECTOR (16-GA TO 18-GA) | 25 | |
| 1261767 | PIN-CONNECTOR (14-GA TO 16-GA) | 25 | |
| 2407877 | PLUG AS-CONNECTOR (2-PIN) | 1 | |
| 2407876 | PLUG AS-CONNECTOR (2-PIN) | 2 | |
| 2647029 | SEAL-CONNECTOR | 1 | |
| 2407879 | PLUG AS-CONNECTOR (3-PIN) | 1 | |
| 2813119 | PLUG AS-CONNECTOR (3-PIN) | 1 | |
| 2813120 | PLUG AS-CONNECTOR (3-PIN) | 1 | |
| 2407878 | PLUG AS-CONNECTOR (3-PIN) | 3 | |
| 2647030 | SEAL-CONNECTOR | 1 | |
| 2813125 | PLUG AS-CONNECTOR (4-PIN) | 1 | |
| 2610524 | PLUG AS-CONNECTOR (4-PIN) | 1 | |
| 2647031 | SEAL-CONNECTOR | 1 | |
| 2813132 | PLUG AS-CONNECTOR (6-PIN) | 1 | |
| 2813134 | PLUG AS-CONNECTOR (6-PIN) | 1 | |
| 2647032 | SEAL-CONNECTOR | 1 | |
| 2813395 | PLUG AS-CONNECTOR (12-PIN) | 1 | |
| 2647034 | SEAL-CONNECTOR | 1 | |
| 8T8737 | PLUG-SEAL | 23 | |
| 3246267 | RECEPTACLE AS-CONNECTOR (40-PIN) | 1 | |
| 9X3402 | SOCKET-CONNECTOR (16-GA TO 18-GA) | 48 | |
| 1261768 | SOCKET-CONNECTOR (14-GA TO 16-GA) | 48 | |
| 2684412 | TAPE-INSULATOR | ||
| 2L8078 | TERMINAL-RING (14-GA TO 16-GA, 5/16-IN SCREW) | 1 | |
| 1257874 | TUBE-HEAT SHRINK (5.72-MM DIA)(10-CM) | ||
| 1193662 | TUBE-HEAT SHRINK (10.85-MM DIA)(7-CM) | ||
| 3648334 | 19 PLATE AS | 1 | |
| 1966723 | 20 BOLT (M10X1.5X70-MM) | 2 | |
| 2856395 | 21 CLIP (LADDER) | 4 | |
| 3118366 | 22 WASHER-HARD (8.8X16X2-MM THK) | 6 | |
| 3413624 | 23 CLIP (LADDER) | 12 | |
| 3441191 | 24 BOLT (M10X1.5X100-MM) | 2 | |
| 3441193 | 25 BOLT (M8X1.25X25-MM) | 1 | |
| 3441199 | 26 WASHER-HARD (11X21X2.5-MM THK) | 6 | |
| 3441200 | 27 WASHER-HARD (6.6X12X2-MM THK) | 8 | |
| 3441201 | 28 BOLT (M10X1.5X20-MM) | 2 | |
| 3441203 | 29 BOLT (M8X1.25X16-MM) | 1 | |
| 3441205 | 30 BOLT (M6X1X12-MM) | 1 | |
| 3441206 | 31 BOLT (M6X1X16-MM) | 8 | |
| 3469081 | 32 SPACER (11X26X75-MM THK) | 2 | |
| 3469082 | 33 SPACER (11X26X45-MM THK) | 2 | |
| 8T9405 | 34 BOLT-SOCKET HEAD (M4X0.7X16-MM) | 1 | |
| 3728827 | 35 INSULATION | 1 |
