System And Components
291-8785 WIRING GP-REARS/N T4P1-UP
Group No: 291-8785 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3E6451 | 1 SWITCH GP-TEMPERATURE (REAR BRAKE) | 1 | |
| 1028802 | KIT-RECEPTACLE (2-PIN) | 1 | |
| 8T8729 | PIN-CONNECTOR (16-GA TO 20-GA) | 2 | |
| 3S2093 | 2 STRAP-CABLE | 61 | |
| 5G7820 | 3 MAGNET AS | 1 | |
| 8W8528 | 4 SLEEVE | 2 | |
| 2295527 | 5 SENSOR GP-POSITION (TRUCK BODY POSITION) | 1 | |
| 1028803 | KIT-RECEPTACLE (3-PIN) | 1 | |
| 1210153 | FILM-INSTRUCTION (ELECTRICAL POWER) | 1 | |
| 2919440 | 6 WARNING GP-BACKUP | 1 | |
| 3337288 | 7 PLATE AS | 1 | |
| 3362815 | 8 HARNESS AS-REAR | 1 | |
| 9X3402 | SOCKET-CONNECTOR (16-GA TO 18-GA) | 5 | |
| 1261768 | SOCKET-CONNECTOR (14-GA TO 16-GA) | 5 | |
| 1809340 | SOCKET-CONNECTOR (14-GA TO 18-GA) | 29 | |
| 2743775 | CAP-CONNECTOR | 1 | |
| 1552260 | KIT-CONNECTING PLUG (3-PIN) | 1 | |
| 1552270 | KIT-CONNECTING PLUG (2-PIN) | 4 | |
| 1552274 | KIT-CONNECTING PLUG (6-PIN) | 3 | |
| 2304011 | PLUG AS-CONNECTOR (2-PIN) | 1 | |
| 2647029 | SEAL-CONNECTOR | 1 | |
| 2304013 | PLUG AS-CONNECTOR (3-PIN) | 1 | |
| 2647030 | SEAL-CONNECTOR | 1 | |
| 2722838 | PLUG AS-CONNECTOR (31-PIN) | 1 | |
| 8T8737 | PLUG-SEAL | 4 | |
| 2743780 | CAP-SEAL | 1 | |
| 8T8730 | SOCKET-CONNECTOR (16-GA TO 20-GA) | 15 | |
| 9W0844 | SOCKET-CONNECTOR (14-GA TO 16-GA) | 12 | |
| 1257874 | TUBE-HEAT SHRINK (5.72-MM DIA)(5-CM) | ||
| 1257875 | TUBE-HEAT SHRINK (7.44-MM DIA)(10-CM) | ||
| 3366684 | 9 CAMERA GP (WORK AREA VISUAL SYSTEM, REAR) | 1 | |
| 3376319 | 10 HARNESS AS-SENSOR (WHEEL SPEED) | 1 | |
| 9X3401 | PIN-CONNECTOR (16-GA TO 18-GA) | 6 | |
| 1261767 | PIN-CONNECTOR (14-GA TO 16-GA) | 6 | |
| 5P5777 | ADAPTER-O-RING | 2 | |
| 3447626 | HOSE AS | 1 | |
| 2P1286 | LOCKNUT-BULKHEAD (1-5/16-12-THD) | 2 | |
| 2407878 | PLUG AS-CONNECTOR (3-PIN) | 2 | |
| 2647030 | SEAL-CONNECTOR | 1 | |
| 1519275 | KIT-RECEPTACLE (6-PIN) | ||
| 9X3402 | SOCKET-CONNECTOR (16-GA TO 18-GA) | 6 | |
| 1P0810 | TAPE-ELECTRICAL | ||
| 3376320 | 11 HARNESS AS-SENSOR (REAR WHEEL) | 1 | |
| 5P5777 | ADAPTER-O-RING | 2 | |
| 3447625 | HOSE AS | 1 | |
| 2P1286 | LOCKNUT-BULKHEAD (1-5/16-12-THD) | 2 | |
| 9X3401 | PIN-CONNECTOR (16-GA TO 18-GA) | 6 | |
| 1261767 | PIN-CONNECTOR (14-GA TO 16-GA) | 6 | |
| 2407878 | PLUG AS-CONNECTOR (3-PIN) | 2 | |
| 2647030 | SEAL-CONNECTOR | 1 | |
| 1519275 | KIT-RECEPTACLE (6-PIN) | 1 | |
| 9X3402 | SOCKET-CONNECTOR (16-GA TO 18-GA) | 6 | |
| 1P0810 | TAPE-ELECTRICAL | ||
| 3445871 | 12 BRACKET | 1 | |
| 3447391 | 13 SENSOR-PRESSURE (PARKING BRAKE) | 1 | |
| 3589889 | 14 PLATE AS | 1 | |
| 3589890 | 15 PLATE AS | 1 | |
| 1599540 | NUT-WELD (M8X1.25-THD) | 1 | |
| 3523965 | 16 CLIP (LADDER) | 1 | |
| 3E4352 | 17 WASHER-HARD (8.8X20.5X2.5-MM THK) | 4 | |
| 3J1907 | 18 SEAL-O-RING | 1 | |
| 3K0360 | 19 SEAL-O-RING | 1 | |
| 4P8134 | 20 CLIP (LADDER) | 1 | |
| 5P4116 | 21 WASHER-HARD (8.8X20.5X2-MM THK) | 6 | |
| 6D4244 | 22 CLIP (LOOP) | 2 | |
| 8T4121 | 23 WASHER-HARD (11X21X2.5-MM THK) | 2 | |
| 8T4189 | 24 BOLT (M8X1.25X20-MM) | 2 | |
| 8T4191 | 25 BOLT (M10X1.5X16-MM) | 2 | |
| 8T4197 | 26 BOLT (M8X1.25X40-MM) | 2 | |
| 8T4200 | 27 BOLT (M8X1.25X16-MM) | 2 | |
| 8T4223 | 28 WASHER-HARD (13.5X25.5X3-MM THK) | 4 | |
| 8T4908 | 30 BOLT (M8X1.25X25-MM) | 4 | |
| 8T4956 | 31 BOLT (M12X1.75X35-MM) | 4 |
