System And Components
308-8122 WIRING GP-TRANSMISSIONS/N K2S1-UP
Group No: 308-8122 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3S2093 | 1 STRAP-CABLE | 17 | |
| 2016615 | 2 SENSOR GP-SPEED (TRANSMISSION) | 1 | |
| 2566453 | 3 SENSOR-TEMPERATURE (2-PIN)(TRANSMISSION OIL) | 1 | |
| 3418378 | 4 HARNESS AS-TRANSMISSION | 1 | |
| 9X3401 | PIN-CONNECTOR (16-GA TO 18-GA) | 23 | |
| 1086259 | PLUG AS-CONNECTOR (17-PIN) | 1 | |
| 1552270 | KIT-CONNECTING PLUG (2-PIN) | 3 | |
| 2304011 | PLUG AS-CONNECTOR (2-PIN) | 1 | |
| 2647029 | SEAL-CONNECTOR | 1 | |
| 8T8737 | PLUG-SEAL | 1 | |
| 9X0145 | RECEPTACLE AS-CONNECTOR (24-PIN) | 1 | |
| 1148843 | SLEEVE-PLASTIC (80-CM) | ||
| 1809340 | SOCKET-CONNECTOR (14-GA TO 18-GA) | 8 | |
| 1P0810 | TAPE-ELECTRICAL | ||
| 3418383 | 5 BRACKET AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 1 | |
| 0S1595 | 6 BOLT (1/2-13X1.25-IN) | 1 | |
| 0S1621 | 7 BOLT (1/2-13X1-IN) | 1 | |
| 1171385 | 8 SEAL-O-RING | 1 | |
| 1325789 | 9 CLIP (LADDER) | 4 | |
| 2771873 | 10 CLIP (LADDER) | 2 | |
| 4B4863 | 11 WASHER (4.7X11X1.2-MM THK) | 4 | |
| 4P7429 | 12 CLIP (LADDER) | 3 | |
| 4P7581 | 13 CLIP (LADDER) | 2 | |
| 4P8134 | 14 CLIP (LADDER) | 5 | |
| 5P8245 | 15 WASHER-HARD (13.5X25.5X3-MM THK) | 1 | |
| 6D5801 | 16 LOCKNUT (8-32-THD) | 4 | |
| 6V7345 | 17 SCREW-MACHINE (8-32X0.875-IN) | 4 | |
| 8L2786 | 18 SEAL-O-RING | 1 | |
| 8T4121 | 19 WASHER-HARD (11X21X2.5-MM THK) | 2 | |
| 8T4137 | 20 BOLT (M10X1.5X20-MM) | 7 | |
| 8T4200 | 21 BOLT (M8X1.25X16-MM) | 2 | |
| 8T4224 | 22 WASHER-HARD (8.8X16X2-MM THK) | 2 | |
| 5P6029 | 23 LOCKWIRE |
