System And Components
371-0565 WHEEL GP-FINAL DRIVE & BRAKES/N T4P1-UP
Group No: 371-0565 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2P1823 | 1 CUP-BEARING (TAPERED ROLLER)(STANDARD) | 1 | |
| 5014310 | CUP-BEARING (HIGH CAPACITY) | 1 | |
| 2P1824 | 2 CONE-BEARING (TAPERED ROLLER)(STANDARD) | 1 | |
| 5014311 | CONE-BEARING (HIGH CAPACITY) | 1 | |
| 9M2744 | 3 CONE-BEARING (TAPERED ROLLER)(STANDARD) | 1 | |
| 5014308 | CONE-BEARING (HIGH CAPACITY) | 1 | |
| 1A1135 | 4 BOLT (5/8-11X2-IN) | 20 | |
| 1M6573 | 5 CUP-BEARING (TAPERED ROLLER)(STANDARD) | 1 | |
| 5014307 | CUP-BEARING (HIGH CAPACITY) | ||
| 1P3958 | 6 ROLLER AS-SPECIAL | 6 | |
| 2D0604 | 7 BUTTON | 1 | |
| 2R0239 | 8 SEAL-O-RING | 1 | |
| 2V5656 | 9 RING-SNAP | 1 | |
| 2V7092 | 10 PLATE-RETAINER | 1 | |
| 2V7390 | 11 SHIM PACK (INCLUDES 15-SHIMS) | 1 | |
| 2V7398 | 12 RING-RETAINING | 3 | |
| 4V4500 | 13 SPACER (51X66X5-MM THK) | 3 | |
| 4V4504 | 14 GEAR-RING (65-TEETH) | 1 | |
| 4V5233 | 15 WASHER-THRUST (48X80X1.6-MM THK) | 6 | |
| 4V5234 | 16 WASHER-THRUST (48X80X1.52-MM THK) | 6 | |
| 4V5237 | 17 CARRIER-PLANETARY | 1 | |
| 5P2861 | 18 SEAL-O-RING | 1 | |
| 1654929 | 19 PLUG AS-MAGNETIC | 2 | |
| 7M8485 | SEAL-O-RING | 1 | |
| 5P4484 | PLUG-MAGNETIC (FINAL DRIVE OIL DRAIN) | 1 | |
| 1471206 | 20 GEAR (23-TEETH) | 3 | |
| 1903593 | 21 SHAFT-PLANETARY | 3 | |
| 2176309 | 22 BRAKE GP-SERVICE | 1 | |
| 2188117 | 23 SPINDLE | 1 | |
| 3012806 | 24 COVER | 1 | |
| 3097664 | 25 SEAL GP-DUO-CONE | 1 | |
| 5P1606 | RING-TORIC | 2 | |
| 3171300 | 26 HUB AS | 1 | |
| 2V5715 | 26A BUSHING-TERMINAL | 1 | |
| 3634457 | 27 KIT-SEAL (HEAVY-DUTY DUAL FACE SEAL) | 1 | |
| 3760969 | 28 WHEEL | 1 | |
| 0S1585 | 29 BOLT (1/2-13X1.5-IN) | 6 | |
| 0S1594 | 30 BOLT (3/8-16X1-IN) | 6 | |
| 3217848 | 31 STUD-WHEEL | 27 | |
| 5P8245 | 32 WASHER-HARD (13.5X25.5X3-MM THK) | 6 | |
| 5P8247 | 33 WASHER-HARD (17X32X3.5-MM THK) | 20 | |
| 7K6058 | 34 BOLT-12 POINT HEAD (1/2-13X2.5-IN) | 8 | |
| 8D2714 | 36 SEAL-O-RING | 1 |
