Assembly
100%

291-9037 BAFFLE GP-RADIATORS/N T4P1-UP

Group No: 291-9037 · Commonality
Part NumberPart NameQty
36245771 BRACKET1
36245832 BAFFLE (TOP)1
36245843 BAFFLE (RH)1
37525544 GUARD1
36542185 BAFFLE AS1
5C72616 NUT (M8X1.25-THD)4
5P41167 WASHER-HARD (8.8X20.5X2-MM THK)21
7X77298 WASHER (11X25X3-MM THK)2
8T41899 BOLT (M8X1.25X20-MM)17
8T419510 BOLT (M10X1.5X30-MM)2
136772811 SEAL (9.8-DM)
136772811A SEAL (2.1-DM)
136772811B SEAL (10.8-DM)
375255512 GUARD1
3E660013 SEAL (12-CM)
3E660013A SEAL (19-CM)
