System And Components
329-8009 FRAME GP-FRONTS/N T4P1-UP
Group No: 329-8009 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1255006 | 1 BOSS AS | 3 | |
| 1629839 | 2 BRACKET | 1 | |
| 1907376 | 3 BRACKET AS | 1 | |
| 1936980 | 4 PLATE AS | 1 | |
| 7T1099 | LINK | 1 | |
| 8T3597 | NUT-WELD (M12X1.75-THD) | 7 | |
| 3298111 | 5 FRAME AS-FRONT | 1 | |
| 7T1099 | LINK | 6 | |
| 8Y4489 | BOSS (M10X1.5X35-MM) | 1 | |
| 3363471 | BRACKET AS | 2 | |
| 3433464 | 6 BRACKET AS | 2 | |
| 6V8224 | NUT-WELD (M10X1.5-THD) | 1 | |
| 7T1099 | LINK | 1 | |
| 3520188 | 7 BRACKET AS | 1 | |
| 1255006 | BOSS AS | 1 | |
| 8T3597 | NUT-WELD (M12X1.75-THD) | 1 | |
| 8Y4489 | BOSS (M10X1.5X35-MM) | 3 | |
| 3520191 | 8 BRACKET AS | 1 | |
| 7Y8763 | BOSS (M10X1.5X25-MM) | 1 | |
| 3457565 | 9 PLATE AS | 1 | |
| 2284586 | BAR | 1 | |
| 8Y4489 | 10 BOSS (M10X1.5X35-MM) | 1 | |
| 9R2672 | 11 BOSS-THREADED (M10X1.5X20-MM) | 1 | |
| 8Y3925 | 12 BOSS (M10X1.5X30-MM) | 1 | |
| 7T1099 | 13 LINK | 5 | |
| 3439863 | 14 BRACKET | 1 | |
| 1905361 | 15 BRACKET AS | 1 | |
| 3571489 | 16 BRACKET | 1 |
