System And Components
291-8940 FRAME GP-REAR -NON-ENGINE ENDS/N T4P1-410
Group No: 291-8940 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1128517 | 1 BUSHING | 2 | |
| 1420050 | 2 BUSHING | 2 | |
| 1420539 | 3 STRUT AS | 1 | |
| 3U8952 | PIN AS | 1 | |
| 1444083 | 4 BRACKET | 1 | |
| 1518455 | 5 PIN AS | 1 | |
| 1625516 | 6 BUSHING | 2 | |
| 1625517 | 7 SEAL | 2 | |
| 1625518 | 8 RING-RETAINING | 2 | |
| 1746769 | 9 FRAME AS-GUARD | 1 | |
| 1892908 | 10 CLAMP AS-BAND | 1 | |
| 1951106 | LOCK-SCREW | 1 | |
| 1951107 | BAND-PERFORATED (2-M) | ||
| 1945012 | 11 DEFLECTOR | 1 | |
| 3345807 | 12 FRAME AS | 1 | |
| 2384751 | HOUSING | 1 | |
| 1412872 | PIVOT-REAR | 1 | |
| 5C9855 | BOSS (M8X1.25X19-MM) | 2 | |
| 7T1099 | LINK | 21 | |
| 9G9155 | CLIP | 2 | |
| 3464765 | 13 PLATE AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 7 | |
| 8T3597 | NUT-WELD (M12X1.75-THD) | 7 | |
| 7X2557 | 14 BOLT (M16X2X140-MM) | 1 | |
| 8T0365 | 15 BOLT (M24X3X240-MM) | 6 | |
| 8T4132 | 16 NUT (M16X2-THD) | 1 | |
| 8T4139 | 17 BOLT (M12X1.75X30-MM) | 4 | |
| 6V8237 | 18 WASHER (26X44X4-MM THK) | 6 | |
| 8T4183 | 19 BOLT (M12X1.75X40-MM) | 9 | |
| 8T4194 | 20 BOLT (M12X1.75X50-MM) | 1 | |
| 8T4223 | 21 WASHER-HARD (13.5X25.5X3-MM THK) | 18 | |
| 8T4244 | 22 NUT (M12X1.75-THD) | 6 | |
| 9X8257 | 23 WASHER (17.5X30X3.5-MM THK) | 2 |
