System And Components
360-7849 FRAME GP-REARS/N T4P1-UP
Group No: 360-7849 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1420050 | 1 BUSHING | 2 | |
| 1444083 | 2 BRACKET | 1 | |
| 1625516 | 3 BUSHING | 2 | |
| 1625517 | 4 SEAL | 2 | |
| 1625518 | 5 RING-RETAINING | 2 | |
| 1746769 | 6 FRAME AS-GUARD | 1 | |
| 1892908 | 7 CLAMP AS-BAND | 1 | |
| 1945012 | 8 DEFLECTOR | 1 | |
| 3464765 | 9 PLATE AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 7 | |
| 8T3597 | NUT-WELD (M12X1.75-THD) | 7 | |
| 3696220 | 10 FRAME AS | 1 | |
| 6V8237 | 11 WASHER (26X44X4-MM THK) | 6 | |
| 8T0365 | 12 BOLT (M24X3X240-MM) | 6 | |
| 8T4139 | 13 BOLT (M12X1.75X30-MM) | 4 | |
| 8T4183 | 14 BOLT (M12X1.75X40-MM) | 8 | |
| 8T4223 | 15 WASHER-HARD (13.5X25.5X3-MM THK) | 16 | |
| 8T4244 | 16 NUT (M12X1.75-THD) | 4 |
