System And Components
291-8958 GUARD GP-PLATFORMS/N T4P1-UP
Group No: 291-8958 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3313931 | 1 HANDRAIL AS | 1 | |
| 3313932 | 2 HANDRAIL AS | 1 | |
| 3313933 | 3 HANDRAIL AS | 1 | |
| 3313934 | 4 HANDRAIL AS | 1 | |
| 3313935 | 5 HANDRAIL AS | 1 | |
| 3313936 | 6 HANDRAIL AS | 1 | |
| 1984777 | 7 WASHER-HARD (11X25X10-MM THK) | 4 | |
| 5P7468 | 8 CLIP (SLOT) | 2 | |
| 5P7469 | 9 CLIP (TAB) | 2 | |
| 6V7687 | 10 LOCKNUT (M12X1.75-THD) | 2 | |
| 7X2621 | 11 BOLT (M10X1.5X12-MM) | 6 | |
| 7X7729 | 12 WASHER (11X25X3-MM THK) | 17 | |
| 8T0389 | 13 LOCKNUT (M10X1.5-THD) | 1 | |
| 8T4175 | 14 BOLT (M16X2X90-MM) | 8 | |
| 8T4186 | 15 BOLT (M10X1.5X40-MM) | 4 | |
| 8T4196 | 16 BOLT (M10X1.5X35-MM) | 16 | |
| 8T4223 | 17 WASHER-HARD (13.5X25.5X3-MM THK) | 8 | |
| 8T4956 | 18 BOLT (M12X1.75X35-MM) | 2 | |
| 8T6868 | 19 BOLT (M12X1.75X80-MM) | 6 | |
| 8T7087 | 20 GROMMET (34-MM ID) | 2 | |
| 9X8257 | 21 WASHER (17.5X30X3.5-MM THK) | 8 |
