System And Components
291-8962 HOOD GP-ENGINES/N T4P1-347
Group No: 291-8962 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3283984 | 1 WIRING GP-LIGHTING | 1 | |
| 3323814 | 2 HOOD AS | 1 | |
| 3595886 | RIB AS | 1 | |
| 7T1099 | LINK | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 8 | |
| 3595889 | RIB AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 8 | |
| 8T3612 | NUT-WELD (M8X1.25-THD) | 4 | |
| 8T4121 | WASHER-HARD (11X21X2.5-MM THK) | 14 | |
| 8T4136 | BOLT (M10X1.5X25-MM) | 14 | |
| 3323816 | 3 GRILL AS (LH) | 1 | |
| 3323817 | 4 GRILL AS (RH) | 1 | |
| 3323818 | 5 HINGE AS (LH) | 1 | |
| 5G8871 | BOSS (M6X1-THD) | 1 | |
| 7T1099 | LINK | 1 | |
| 3323819 | 6 HINGE AS (RH) | 1 | |
| 5G8871 | BOSS (M6X1-THD) | 1 | |
| 7T1099 | LINK | 3 | |
| 3323821 | 7 BUSHING-FLANGE | 2 | |
| 3323822 | 8 DUCT AS | 1 | |
| 8T4224 | WASHER-HARD (8.8X16X2-MM THK) | 4 | |
| 8T4908 | BOLT (M8X1.25X25-MM) | 4 | |
| 3323830 | 9 GRILL AS | 1 | |
| 3429929 | 10 FAN & MOTOR AS | 1 | |
| 3510978 | BLADE-FAN | 1 | |
| 1779645 | KIT-RECEPTACLE (2-PIN) | 1 | |
| 2434507 | RECEPTACLE AS-CONNECTOR (4-PIN) | 1 | |
| 3479021 | 11 GUARD AS-FAN | 1 | |
| 3514733 | 12 PANEL AS | 1 | |
| 3514734 | 13 PANEL AS (LH) | 1 | |
| 3514735 | 14 PANEL AS (RH) | 1 | |
| 3514744 | 15 VENT | 1 | |
| 3581460 | 16 INSULATION | 1 | |
| 3581461 | 17 INSULATION | 1 | |
| 3581462 | 18 INSULATION | 1 | |
| 3581463 | 19 INSULATION | 1 | |
| 3581464 | 20 INSULATION | 1 | |
| 3581465 | 21 SHIELD-HEAT | 1 | |
| 3581466 | 22 SHIELD-HEAT | 1 | |
| 3595892 | 23 HINGE AS | 2 | |
| 3595895 | 24 HINGE AS | 2 | |
| 3596322 | 25 BRACKET AS | 1 | |
| 8T3612 | NUT-WELD (M8X1.25-THD) | 2 | |
| 3596325 | 26 BRACKET AS | 1 | |
| 3633870 | 27 BRACKET AS | 1 | |
| 3633871 | 28 BRACKET AS | 1 | |
| 8T3612 | NUT-WELD (M8X1.25-THD) | 2 | |
| 3638613 | 29 FENDER GP (FRONT) | 1 | |
| 3651586 | 30 PIN-GUIDE | 2 | |
| 3722830 | 31 BRACKET AS | 1 | |
| 3750094 | 32 SEAL AS (LH) | 1 | |
| 3651587 | SEAL (300-CM) | ||
| 3750095 | 33 SEAL AS (RH) | 1 | |
| 3651587 | SEAL (280-CM) | ||
| 3807951 | 34 BRACKET AS | 1 | |
| 1560283 | 35 WASHER-HARD (8.4X35X2.5-MM THK) | 12 | |
| 1V6688 | 36 GROMMET | 1 | |
| 2167352 | 37 SCREW-TRUSS HEAD (M8X1.25X30-MM) | 4 | |
| 2451094 | 38 NUT-RETAINING | 4 | |
| 3E8020 | 39 SCREW-TRUSS HEAD (M6X1X25-MM) | 8 | |
| 5P1076 | 40 WASHER-HARD (13.5X30X4-MM THK) | 6 | |
| 5P4116 | 41 WASHER-HARD (8.8X20.5X2-MM THK) | 17 | |
| 6V7357 | 42 BOLT (M6X1X25-MM) | 4 | |
| 6V9189 | 43 LOCKNUT (M8X1.25-THD) | 24 | |
| 8T4121 | 44 WASHER-HARD (11X21X2.5-MM THK) | 14 | |
| 8T4183 | 45 BOLT (M12X1.75X40-MM) | 6 | |
| 8T4186 | 46 BOLT (M10X1.5X40-MM) | 6 | |
| 8T4189 | 47 BOLT (M8X1.25X20-MM) | 16 | |
| 8T4195 | 48 BOLT (M10X1.5X30-MM) | 8 | |
| 8T4224 | 49 WASHER-HARD (8.8X16X2-MM THK) | 34 | |
| 8T4908 | 50 BOLT (M8X1.25X25-MM) | 11 | |
| 8T7547 | 51 BOLT (M8X1.25X30-MM) | 8 | |
| 9X2038 | 52 WASHER (7X19X2-MM THK) | 8 | |
| 9X8256 | 53 WASHER (6.6X12X2-MM THK) | 4 | |
| 2228450 | 54 SEAL (89-CM) | ||
| 2225093 | 55 SEAL (220-CM) |
