System And Components
160-8009 BRAKE GP-PARKINGS/N T4P1-UP
Group No: 160-8009 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2060408 | 1 ACTUATOR AS-PARKING BRAKE | 1 | |
| 1548042 | ACTUATOR (PARKING BRAKE) | 1 | |
| 2060407 | BOOT | 1 | |
| 1723931 | 2 PIN | 1 | |
| 1723932 | 3 SPACER | 2 | |
| 3B4610 | 4 PIN-COTTER | 1 | |
| 8T4223 | 5 WASHER-HARD (13.5X25.5X3-MM THK) | 2 | |
| 8T4244 | 6 NUT (M12X1.75-THD) | 2 | |
| 3460331 | 7 END-YOKE ROD | 1 | |
| 8C8992 | 8 BOLT-LOCKING (M12X1.75X30-MM) | 6 | |
| 8T5091 | 9 BOLT (M8X1.25X20-MM) | 2 | |
| 8T6869 | 10 BOLT (M8X1.25X60-MM) | 1 | |
| 5C7261 | 11 NUT (M8X1.25-THD) | 1 | |
| 1723934 | 12 SPRING | 2 | |
| 6C8608 | 13 PIN | 1 | |
| 3B4607 | 14 PIN-COTTER | 1 | |
| 1723935 | 15 PLUG | 1 | |
| 4W9026 | 16 GASKET | 1 | |
| 6V1506 | 17 FITTING-GREASE | 1 | |
| 2799438 | KIT-ADJUSTER | 1 | |
| 2799439 | KIT-SLEEVE | 1 | |
| 2799440 | KIT-PIN | 1 | |
| 2799441 | KIT-SHAFT | ||
| 2799442 | KIT-BAR | 1 | |
| 2799444 | KIT-BRAKE LINING | 1 | |
| 2799674 | KIT-SEAL | 1 | |
| 3458544 | KIT-BRAKE SADDLE | 1 | |
| 3429202 | KIT-BEARING | 1 | |
| 2673540 | KIT-LEVER | 1 |
