System And Components
217-6309 BRAKE GP-SERVICES/N T4P1-UP
Group No: 217-6309 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 5H3701 | 1 SCREW-PURGE | 1 | |
| 9J5491 | 2 SPRING | 4 | |
| 1339883 | 3 PISTON | 1 | |
| 1342562 | 4 GUIDE | 4 | |
| 1378116 | 5 RING-SEAL | 1 | |
| 1378117 | 6 SEAL-RING | 1 | |
| 1378118 | 7 RING-SEAL | 1 | |
| 1378119 | 8 SEAL-RING | 1 | |
| 1488406 | 9 PLUG AS | 4 | |
| 9S9334 | PLUG (1-5/16-12-THD) | 1 | |
| 7M8485 | SEAL-O-RING | 1 | |
| 1488410 | 10 PLUG AS | 1 | |
| 2M9780 | SEAL-O-RING | 1 | |
| 9S4190 | PLUG-O-RING (7/8-14-THD) | 1 | |
| 1644180 | 11 PLUG AS | 3 | |
| 9S4181 | PLUG (1-5/16-12-THD) | 1 | |
| 7M8485 | SEAL-O-RING | 1 | |
| 1953834 | 12 SETSCREW (M12X1.75X110-MM) | 3 | |
| 3760968 | 13 PLATE | 1 | |
| 2188119 | 14 ANCHOR | 1 | |
| 2188120 | 15 HOUSING | 1 | |
| 5P8245 | 16 WASHER-HARD (13.5X25.5X3-MM THK) | 59 | |
| 6M9155 | 17 PIN | 4 | |
| 6V8336 | 18 BOLT (M12X1.75X70-MM) | 59 | |
| 6W4310 | 19 SEAL-O-RING | 1 | |
| 8T4223 | 20 WASHER-HARD (13.5X25.5X3-MM THK) | 3 | |
| 8T4244 | 21 NUT (M12X1.75-THD) | 3 | |
| 8W9707 | 22 DAMPER AS | 2 | |
| 9H0846 | 23 SEAL-O-RING | 1 | |
| 9V6164 | 24 PLATE-OUTER | 10 | |
| 3781879 | 25 DISC-FRICTION | 11 |
