System And Components
360-2832 CONTROL GP-PARKING BRAKE -TRAILERS/N T4P1-UP
Group No: 360-2832 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 6U0456 | 1 STRAP | 3 | |
| 6V0852 | 2 CAP-DUST (HYDRAULIC OIL) | 1 | |
| 1284197 | 3 HOSE AS | 1 | |
| 1488318 | 4 CONNECTOR AS | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V8634 | CONNECTOR | 1 | |
| 1635632 | 5 ACCUMULATOR GP-BRAKE (CHARGED)(PARKING) | 1 | |
| 1645567 | 6 COUPLER AS-QUICK DISCONNECT (MALE) | 1 | |
| 6V3965 | FITTING (QUICK DISCONNECT) | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 1906278 | 7 HOSE AS | 1 | |
| 1906290 | 8 VALVE GP-BRAKE CONTROL (PARKING) | 1 | |
| 2023063 | 9 BRACKET | 1 | |
| 2142179 | 10 TUBE AS | 1 | |
| 2225608 | 11 ELBOW AS | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 2225609 | ELBOW | 1 | |
| 2226869 | 12 CONNECTOR AS | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 9X2614 | CONNECTOR | 1 | |
| 2519991 | 13 HOSE AS | 1 | |
| 2942547 | 14 ELBOW AS | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 1014845 | PLUG-ORIFICE | 1 | |
| 2942630 | ELBOW | 1 | |
| 3602843 | 15 TUBE AS | 1 | |
| 1488353 | 16 ELBOW AS | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V9001 | ELBOW | 1 | |
| 1488361 | 17 ELBOW AS (90-DEG) | 1 | |
| 3J7354 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V9200 | ELBOW | 1 | |
| 1488375 | 18 ELBOW AS | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 6V8981 | ELBOW | 1 | |
| 1488377 | 19 ELBOW AS | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V8980 | ELBOW | 1 | |
| 5P4116 | 20 WASHER-HARD (8.8X20.5X2-MM THK) | 2 | |
| 6V9168 | 21 NUT (11/16-16-THD) | 1 | |
| 6V9169 | 22 NUT (13/16-16-THD) | 1 | |
| 7X7729 | 23 WASHER (11X25X3-MM THK) | 2 | |
| 8T1885 | 24 CLIP (SLOT) | 2 | |
| 8T1886 | 25 CLIP (TAB) | 2 | |
| 8T1887 | 26 CLIP (SLOT) | 1 | |
| 8T1888 | 27 CLIP (TAB) | 1 | |
| 8T4121 | 28 WASHER-HARD (11X21X2.5-MM THK) | 2 | |
| 8T4133 | 29 NUT (M10X1.5-THD) | 1 | |
| 8T4137 | 30 BOLT (M10X1.5X20-MM) | 2 | |
| 8T4196 | 31 BOLT (M10X1.5X35-MM) | 1 | |
| 8T6870 | 32 BOLT (M8X1.25X70-MM) | 2 | |
| 8W8909 | 33 SLEEVE | 1 |
