System And Components
354-0748 CONTROL GP-SERVICE BRAKE -COLD WEATHERS/N T4P1-UP
Group No: 354-0748 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2W9710 | 1 MOUNT AS | 3 | |
| 3E2345 | 2 ADAPTER-TEE | 2 | |
| 6N6984 | 3 MOUNT-RUBBER | 9 | |
| 6V0852 | 5 CAP-DUST (HYDRAULIC OIL) | 2 | |
| 9F2167 | 6 SCREW-PURGE (3/8-24X1.164-IN) | 2 | |
| 1088393 | 7 CAP | 2 | |
| 2087969 | 8 HOSE AS | 1 | |
| 1413983 | 9 SPACER (11X19X48-MM THK) | 2 | |
| 1645586 | 10 TEE AS | 2 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 7X0871 | TEE | 1 | |
| 1659993 | 11 HOSE AS | 1 | |
| 1697403 | 12 ADAPTER AS | 2 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6G3432 | ADAPTER | 1 | |
| 1808145 | 13 SEAL | 1 | |
| 1833873 | 14 BREATHER (BRAKE CONTROL VALVE) | 1 | |
| 2087973 | 15 HOSE AS | 1 | |
| 2087974 | 16 HOSE AS | 1 | |
| 2087975 | 17 HOSE AS | 1 | |
| 2099136 | 18 HOSE AS | 1 | |
| 2511934 | 19 TUBE AS | 1 | |
| 2511935 | 20 TUBE AS | 1 | |
| 2087970 | 21 HOSE AS | 1 | |
| 3435502 | 22 HOSE AS | 1 | |
| 3510628 | 23 VALVE GP-BRAKE CONTROL (SERVICE) | 1 | |
| 3540737 | 24 PLATE | 1 | |
| 3587609 | 25 ACCUMULATOR & MTG GP-BRAKE (COLD WEATHER) | 1 | |
| 3588792 | 26 TUBE AS | 1 | |
| 3588793 | 27 TUBE AS | 1 | |
| 1488340 | 28 CONNECTOR AS | 2 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 6V8639 | CONNECTOR | 1 | |
| 1488364 | 29 ELBOW AS | 4 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 6V8625 | ELBOW | 1 | |
| 1488418 | 30 REDUCER AS | 2 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 6V8942 | REDUCER-O-RING | 1 | |
| 1488427 | 31 TEE AS | 2 | |
| 6V8398 | SEAL-O-RING | 3 | |
| 8T6895 | TEE-UNION | 1 | |
| 1488457 | 32 UNION AS (STRAIGHT) | 4 | |
| 6V8398 | SEAL-O-RING | 2 | |
| 6V8995 | UNION (STRAIGHT) | 1 | |
| 1645567 | 33 COUPLER AS-QUICK DISCONNECT (MALE) | 2 | |
| 6V3965 | FITTING (QUICK DISCONNECT) | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 1645580 | 34 TEE AS | 1 | |
| 6V8398 | SEAL-O-RING | 2 | |
| 6V9489 | TEE-BULKHEAD | 1 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 1646864 | 35 ELBOW AS | 2 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 7J9108 | SEAL-O-RING | 1 | |
| 8T1810 | ELBOW | 1 | |
| 3D2824 | 36 SEAL-O-RING | 2 | |
| 6V1228 | 37 CLIP | 1 | |
| 6V9169 | 38 NUT (13/16-16-THD) | 9 | |
| 6V9746 | 39 SEAL-O-RING | 2 | |
| 8M4069 | 40 WASHER (10.3X38.1X5-MM THK) | 12 | |
| 8T4121 | 41 WASHER-HARD (11X21X2.5-MM THK) | 17 | |
| 8T4186 | 42 BOLT (M10X1.5X40-MM) | 7 | |
| 8T4191 | 43 BOLT (M10X1.5X16-MM) | 3 | |
| 8T4195 | 44 BOLT (M10X1.5X30-MM) | 2 | |
| 8T4196 | 45 BOLT (M10X1.5X35-MM) | 3 | |
| 8T5005 | 46 BOLT (M10X1.5X70-MM) | 2 | |
| 9X6580 | 47 NUT (1-3/16-12-THD) | 2 | |
| 9X8250 | 48 CLIP (LOOP) | 3 | |
| 8T4123 | 49 WASHER (22X35X3.5-MM THK) | 1 | |
| 8T4167 | 50 WASHER-HARD (26X44X4-MM THK) | 1 |
