System And Components
445-0145 LINES GP-BRAKES/N T4P1-UP
Group No: 445-0145 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1488434 | 1 TEE AS | 1 | |
| 6V8397 | SEAL-O-RING | 2 | |
| 6V9843 | TEE | 1 | |
| 1488444 | 2 TEE AS-SWIVEL | 1 | |
| 6V8398 | SEAL-O-RING | 2 | |
| 6V9837 | TEE-SWIVEL | 1 | |
| 3E7675 | 3 SWITCH GP-PRESSURE (BRAKE) | 3 | |
| 1028803 | KIT-RECEPTACLE (3-PIN) | 1 | |
| 8T8729 | PIN-CONNECTOR (16-GA TO 20-GA) | 3 | |
| 9X1813 | SLEEVE (21-CM) | ||
| 6U0455 | 4 STRAP | 8 | |
| 6U0456 | 5 STRAP | 6 | |
| 7K1181 | 6 STRAP-CABLE | 4 | |
| 9F2167 | 7 SCREW-PURGE (3/8-24X1.164-IN) | 2 | |
| 1412760 | 8 FUSE (7.5-AMPERE) | 1 | |
| 2966980 | 9 SPACER (11X25X30-MM THK) | 1 | |
| 4450135 | 10 HOSE AS | 1 | |
| 4450136 | 11 HOSE AS | 1 | |
| 4450137 | 12 HOSE AS | 1 | |
| 4450138 | 13 HOSE AS | 1 | |
| 4450139 | 14 HOSE AS | 1 | |
| 4450140 | 15 HOSE AS | 1 | |
| 4450141 | 16 BRACKET AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 2 | |
| 4450142 | 17 BRACKET | 1 | |
| 4450143 | 18 PLATE | 1 | |
| 4516894 | 19 BRACKET | 1 | |
| 5166915 | 20 HARNESS AS-CAB | 1 | |
| 5356877 | 21 HARNESS AS-CHASSIS | 1 | |
| 4449512 | 22 VALVE GP-COMBINATION | 1 | |
| 0960192 | 23 LOCKWASHER | 8 | |
| 1488340 | 24 CONNECTOR AS | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 6V8639 | CONNECTOR | 1 | |
| 1488345 | 25 CONNECTOR AS | 1 | |
| 2M9780 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 6V8638 | CONNECTOR | ||
| 1488358 | 26 ELBOW AS | 1 | |
| 2M9780 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 6V8624 | ELBOW | 1 | |
| 1488364 | 27 ELBOW AS | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 6V8625 | ELBOW | 1 | |
| 1488370 | 28 ELBOW AS | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 6V9851 | ELBOW | 1 | |
| 1488372 | 29 ELBOW AS | 2 | |
| 2M9780 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 6V8721 | ELBOW | 1 | |
| 1645567 | 30 COUPLER AS-QUICK DISCONNECT (MALE) | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 6V3965 | FITTING (QUICK DISCONNECT) | 1 | |
| 1787023 | 31 BOSS (M10X1.5X30-MM) | 2 | |
| 2771873 | 32 CLIP (LADDER) | 1 | |
| 3E4321 | 33 CLIP (LOOP) | 2 | |
| 3S2093 | 34 STRAP-CABLE | 26 | |
| 4429366 | 35 SWITCH AS-ROCKER (CAB) | 1 | |
| 4P7581 | 36 CLIP (LADDER) | 1 | |
| 4P8134 | 37 CLIP (LADDER) | 2 | |
| 5P7464 | 38 CLIP (SLOT) | 2 | |
| 5P7465 | 39 CLIP (TAB) | 2 | |
| 5P9085 | 40 CLIP (LOOP) | 2 | |
| 6D4246 | 41 CLIP (LOOP) | 3 | |
| 6V0852 | 42 CAP-DUST | 1 | |
| 6V1249 | 43 GROMMET (22-MM ID) | 2 | |
| 6V1867 | 44 CLIP (SLOT) | 1 | |
| 6V1868 | 45 CLIP (TAB) | 1 | |
| 6V1869 | 46 GROMMET (65-MM ID) | 1 | |
| 6V7744 | 47 LOCKNUT (M10X1.5-THD) | 2 | |
| 6V9672 | 48 SCREW-MACHINE (M4X0.7X16-MM) | 4 | |
| 7C4354 | 49 CLIP | 1 | |
| 7X7729 | 50 WASHER (11X25X3-MM THK) | 2 | |
| 8T2659 | 51 LOCKNUT (M4X0.7-THD) | 4 | |
| 8T4121 | 52 WASHER-HARD (11X21X2.5-MM THK) | 13 | |
| 8T4133 | 53 NUT (M10X1.5-THD) | 3 | |
| 8T4136 | 54 BOLT (M10X1.5X25-MM) | 7 | |
| 8T4178 | 55 BOLT (M10X1.5X90-MM) | 1 | |
| 8T4183 | 56 BOLT (M12X1.75X40-MM) | 4 | |
| 8T4199 | 57 BOLT (M8X1.25X12-MM) | 2 | |
| 8T4223 | 58 WASHER-HARD (13.5X25.5X3-MM THK) | 8 | |
| 8T4224 | 59 WASHER-HARD (8.8X16X2-MM THK) | 2 | |
| 8T5436 | 60 BOLT (M10X1.5X130-MM) | 2 | |
| 8T8549 | 61 LOCKNUT (M12X1.75-THD) | 4 | |
| 1893158 | 62 SUPPRESSOR-ARC | 2 |
