System And Components
291-8777 LINES GP-SERVICE BRAKES/N T4P1-UP
Group No: 291-8777 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 6U0456 | 1 STRAP | 1 | |
| 1930849 | 2 HOSE AS | 1 | |
| 2079519 | 3 HOSE AS | 1 | |
| 2191393 | 4 BRACKET | 1 | |
| 3412972 | 5 HOSE AS | 1 | |
| 1488354 | 6 ELBOW AS | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 6V9002 | ELBOW | 1 | |
| 1488375 | 7 ELBOW AS | 1 | |
| 6V8398 | SEAL-O-RING | 2 | |
| 6V8981 | ELBOW | 1 | |
| 1488382 | 8 ELBOW AS | 1 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 7J9108 | SEAL-O-RING | 1 | |
| 8T0404 | ELBOW | 1 | |
| 1697404 | 9 ELBOW AS | 1 | |
| 6V8982 | ELBOW | 1 | |
| 7J9108 | SEAL-O-RING | 2 | |
| 5P7464 | 10 CLIP (SLOT) | 3 | |
| 5P7465 | 11 CLIP (TAB) | 3 | |
| 5P7470 | 12 CLIP (SLOT) | 1 | |
| 5P7471 | 13 CLIP (TAB) | 1 | |
| 5P7703 | 14 GROMMET (52-MM ID) | 1 | |
| 6V1867 | 15 CLIP (SLOT) | 1 | |
| 6V1868 | 16 CLIP (TAB) | 1 | |
| 6V1869 | 17 GROMMET (65-MM ID) | 1 | |
| 6V7359 | 18 GROMMET (25-MM ID, 37-MM OD) | 1 | |
| 6V9169 | 19 NUT (13/16-16-THD) | 1 | |
| 6V9170 | 20 NUT-BULKHEAD (1-14-THD) | 1 | |
| 8T2920 | 21 GROMMET (27-MM ID) | 2 | |
| 8T4123 | 22 WASHER (22X35X3.5-MM THK) | 1 | |
| 8T4139 | 23 BOLT (M12X1.75X30-MM) | 1 | |
| 8T4167 | 24 WASHER-HARD (26X44X4-MM THK) | 1 | |
| 8T4183 | 25 BOLT (M12X1.75X40-MM) | 2 | |
| 8T4223 | 26 WASHER-HARD (13.5X25.5X3-MM THK) | 5 | |
| 8T4244 | 27 NUT (M12X1.75-THD) | 1 | |
| 8T4956 | 28 BOLT (M12X1.75X35-MM) | 1 | |
| 2905562 | 29 MOUNT (DUAL SWIVEL) | 1 | |
| 6U0455 | 30 STRAP | 2 |
