System And Components
349-4658 LINES GP-SERVICE BRAKE -AXLE, FRONTS/N T4P1-UP
Group No: 349-4658 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 9R3695 | 1 HOSE AS | 2 | |
| 1519817 | 2 BRACKET AS | 1 | |
| 8T3597 | NUT-WELD (M12X1.75-THD) | 2 | |
| 1986824 | 3 TUBE AS | 1 | |
| 2242454 | 4 MANIFOLD AS | 1 | |
| 3502989 | 5 TUBE AS | 1 | |
| 1488342 | 6 CONNECTOR AS | 2 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 6V8632 | CONNECTOR | 1 | |
| 7J9108 | SEAL-O-RING | 1 | |
| 1553504 | 7 ELBOW AS | 2 | |
| 2M9780 | SEAL-O-RING | 1 | |
| 6V9003 | ELBOW | 1 | |
| 7J9108 | SEAL-O-RING | 1 | |
| 5P1076 | 8 WASHER-HARD (13.5X30X4-MM THK) | 2 | |
| 7J9108 | 9 SEAL-O-RING | 2 | |
| 7X0732 | 10 WASHER-HARD (10X22.5X8-MM THK) | 2 | |
| 8T4121 | 11 WASHER-HARD (11X21X2.5-MM THK) | 2 | |
| 8T4136 | 12 BOLT (M10X1.5X25-MM) | 2 | |
| 8T4192 | 13 BOLT (M12X1.75X25-MM) | 2 | |
| 9R1004 | 14 CLIP (TAB) | 2 | |
| 9R1005 | 15 CLIP (SLOT) | 2 |
