System And Components
307-3073 MOTOR GP-PISTON -2-SPEED, RHS/N SRS2966-UP
Group No: 307-3073
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3417647 | 1 VALVE GP-SPEED CONTROL (2-SPEED) | 1 | |
| 2807850 | 2 KIT-VALVE (DISTRIBUTION) | 1 | |
| 5357937 | 3 KIT-BEARING (PISTON MOTOR) | 1 | |
| 2807840 | 4 KIT-BRAKE (PISTON MOTOR) | 1 | |
| 2721882 | 5 STUD-TAPERLOCK (M12X1.75X80-MM) | 2 | |
| 3417649 | 6 SHAFT-DRIVE | 1 | |
| 4374249 | 7 VALVE GP-FLUSHING (PISTON MOTOR) | 1 | |
| 3390443 | 8 KIT-RETAINER | 1 | |
| 2807849 | KIT-SEAL (PISTON MOTOR) |
