System And Components
326-5672 LINES GP-COUPLER -WITH MANUAL LOWERING CONTROLS/N TSL1-UP
Group No: 326-5672
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 9X6581 | 1 NUT-O-RING SEAL (1-14-THD) | 1 | |
| 1242456 | 2 FILM-INSTRUCTION (NO STEP) | 1 | |
| 2079737 | 3 BRACKET AS | 1 | |
| 2079756 | 4 HOSE AS | 4 | |
| 2126690 | 5 GUARD | 1 | |
| 2186245 | 6 HOSE AS | 2 | |
| 2194335 | 7 HOSE AS | 2 | |
| 2337128 | 8 MANIFOLD GP-CONTROL (QUICK COUPLER) | 1 | |
| 2520342 | 9 TUBE AS | 1 | |
| 2520343 | 10 TUBE AS | 1 | |
| 3265674 | 11 TUBE AS | 1 | |
| 3265762 | 12 BRACKET AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 4 | |
| 3265763 | 13 HOSE AS | 1 | |
| 1488325 | 14 CONNECTOR AS | 4 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 4J5477 | SEAL-O-RING | 1 | |
| 6V8641 | CONNECTOR | 1 | |
| 1488336 | 15 CONNECTOR AS | 2 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V8636 | CONNECTOR | 1 | |
| 1488353 | 16 ELBOW AS | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V9001 | ELBOW | 1 | |
| 1488378 | 17 ELBOW AS | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V8724 | ELBOW | 1 | |
| 1488433 | 18 TEE AS | 1 | |
| 6V8397 | SEAL-O-RING | 2 | |
| 6V9836 | TEE-SWIVEL | 1 | |
| 1488446 | 19 TEE AS-SWIVEL | 1 | |
| 6V9838 | TEE-SWIVEL | 1 | |
| 7J9108 | SEAL-O-RING | 2 | |
| 1504034 | 20 TEE AS | 2 | |
| 6V8397 | SEAL-O-RING | 3 | |
| 8T0379 | TEE-BULKHEAD | 1 | |
| 1564282 | 21 REDUCER AS | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V8938 | REDUCER | 1 | |
| 1F7567 | 22 CLIP (LOOP) | 1 | |
| 2V3216 | 23 CLIP (LOOP) | 4 | |
| 3S2093 | 24 STRAP-CABLE | 1 | |
| 4P7581 | 25 CLIP (LADDER) | 1 | |
| 6V8397 | 26 SEAL-O-RING | 4 | |
| 6V9168 | 27 NUT (11/16-16-THD) | 2 | |
| 7B1597 | 28 CLIP | 1 | |
| 7G2950 | 29 CLIP (SLOT) | 1 | |
| 7G2951 | 30 CLIP (TAB) | 1 | |
| 7H7055 | 31 CLIP | 2 | |
| 7X7729 | 32 WASHER (11X25X3-MM THK) | 4 | |
| 8T4121 | 33 WASHER-HARD (11X21X2.5-MM THK) | 4 | |
| 8T4136 | 34 BOLT (M10X1.5X25-MM) | 1 | |
| 8T4189 | 35 BOLT (M8X1.25X20-MM) | 4 | |
| 8T4191 | 36 BOLT (M10X1.5X16-MM) | 3 | |
| 8T4201 | 37 BOLT-LOCKING (M10X1.5X20-MM) | 3 | |
| 8T4224 | 38 WASHER-HARD (8.8X16X2-MM THK) | 4 | |
| 8T5005 | 39 BOLT (M10X1.5X70-MM) | 2 | |
| 9M8406 | 40 CLIP (LOOP) | 2 | |
| 9S1350 | 41 CLIP | 1 | |
| 2126521 | 42 SWITCH AS-ROCKER (QUICK COUPLER) | 1 | |
| 1117899 | GASKET | 1 |
