System And Components
332-8541 LINES GP-COUPLER -WITH MANUAL LOWERING CONTROLS/N TNK1-UP
Group No: 332-8541
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2K5232 | 1 SPACER (0.406X0.75X1.81-IN THK) | 2 | |
| 3S2093 | 2 STRAP-CABLE | 2 | |
| 7K1181 | 3 STRAP-CABLE | 2 | |
| 9X6581 | 4 NUT-O-RING SEAL (1-14-THD) | 1 | |
| 1242456 | 5 FILM-INSTRUCTION (NO STEP) | 1 | |
| 2079737 | 6 BRACKET AS | 1 | |
| 2079756 | 7 HOSE AS | 4 | |
| 2079758 | 8 HOSE AS | 2 | |
| 2126690 | 9 GUARD | 1 | |
| 2185943 | 10 TUBE AS | 1 | |
| 2185944 | 11 TUBE AS | 1 | |
| 2337128 | 12 MANIFOLD GP-CONTROL (QUICK COUPLER) | 1 | |
| 3265584 | 13 TUBE AS | 1 | |
| 3265586 | 14 HOSE AS | 2 | |
| 3265637 | 15 HOSE AS | 1 | |
| 3265762 | 16 BRACKET AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 4 | |
| 1488325 | 17 CONNECTOR AS | 4 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 4J5477 | SEAL-O-RING | 1 | |
| 6V8641 | CONNECTOR | 1 | |
| 1488336 | 18 CONNECTOR AS | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V8636 | CONNECTOR | 1 | |
| 1488353 | 19 ELBOW AS | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V9001 | ELBOW | 1 | |
| 1488378 | 20 ELBOW AS | 2 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V8724 | ELBOW | 1 | |
| 1488433 | 21 TEE AS | 1 | |
| 6V8397 | SEAL-O-RING | 2 | |
| 6V9836 | TEE-SWIVEL | 1 | |
| 1488446 | 22 TEE AS-SWIVEL | 1 | |
| 6V9838 | TEE-SWIVEL | 1 | |
| 7J9108 | SEAL-O-RING | 2 | |
| 1504034 | 23 TEE AS | 2 | |
| 6V8397 | SEAL-O-RING | 3 | |
| 8T0379 | TEE-BULKHEAD | 1 | |
| 1564282 | 24 REDUCER AS | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V8938 | REDUCER | 1 | |
| 1644225 | 25 CLIP | 2 | |
| 1P7009 | 26 CLIP | 1 | |
| 4P7581 | 27 CLIP (LADDER) | 2 | |
| 5C7261 | 28 NUT (M8X1.25-THD) | 2 | |
| 5K8451 | 29 CLIP (LOOP) | 1 | |
| 5P4116 | 30 WASHER-HARD (8.8X20.5X2-MM THK) | 2 | |
| 5P9297 | 31 CLIP (LOOP) | 1 | |
| 6K8178 | 32 CLIP (LOOP) | 2 | |
| 6V8397 | 33 SEAL-O-RING | 4 | |
| 6V9168 | 34 NUT (11/16-16-THD) | 2 | |
| 7G2950 | 35 CLIP (SLOT) | 1 | |
| 7G2951 | 36 CLIP (TAB) | 1 | |
| 7H7055 | 37 CLIP | 8 | |
| 7X7729 | 38 WASHER (11X25X3-MM THK) | 3 | |
| 8T4121 | 39 WASHER-HARD (11X21X2.5-MM THK) | 10 | |
| 8T4133 | 40 NUT (M10X1.5-THD) | 2 | |
| 8T4136 | 41 BOLT (M10X1.5X25-MM) | 1 | |
| 8T4137 | 42 BOLT (M10X1.5X20-MM) | 1 | |
| 8T4189 | 43 BOLT (M8X1.25X20-MM) | 4 | |
| 8T4191 | 44 BOLT (M10X1.5X16-MM) | 2 | |
| 8T4201 | 45 BOLT-LOCKING (M10X1.5X20-MM) | 3 | |
| 8T4224 | 46 WASHER-HARD (8.8X16X2-MM THK) | 6 | |
| 8T4908 | 47 BOLT (M8X1.25X25-MM) | 2 | |
| 8T5005 | 48 BOLT (M10X1.5X70-MM) | 4 | |
| 9M8406 | 49 CLIP (LOOP) | 3 | |
| 9R1004 | 50 CLIP (TAB) | 1 | |
| 9R1005 | 51 CLIP (SLOT) | 1 | |
| 2126521 | 52 SWITCH AS-ROCKER (QUICK COUPLER) | 1 | |
| 1117899 | GASKET | 1 |
