System And Components
326-5677 LINES GP-LIFT CYLINDER -WITH WORK TOOL POSITIONERS/N TNK1-UP
Group No: 326-5677
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1121817 | 1 VALVE-BALL (LIFT CYLINDER) | 1 | |
| 1429116 | 2 SWITCH GP-ROCKER (WORK TOOL POSITIONER) | 1 | |
| 1908074 | 3 HOSE AS | 2 | |
| 1908075 | 4 HOSE AS | 2 | |
| 2185977 | 5 PLATE AS | 1 | |
| 2186438 | 6 SEAL | 1 | |
| 2238418 | 7 MANIFOLD & SOLENOID GP-CONTROL (WORK TOOL POSITIONER) | 1 | |
| 2893765 | 8 TUBE AS | 1 | |
| 2893766 | 9 TUBE AS | 1 | |
| 2893777 | 10 TUBE AS | 1 | |
| 2893778 | 11 TUBE AS | 1 | |
| 2893779 | 12 TUBE AS | 1 | |
| 3265581 | 13 HOSE AS | 1 | |
| 3265590 | 14 TUBE AS | 1 | |
| 3265612 | 15 HOSE AS | 1 | |
| 3265614 | 16 HANDLE AS | 1 | |
| 3265634 | 17 BRUSH AS | 1 | |
| 3265640 | 18 BRACKET AS | 1 | |
| 1599539 | NUT-WELD (M6X1-THD) | 3 | |
| 1599540 | NUT-WELD (M8X1.25-THD) | 3 | |
| 7X0579 | 19 WASHER-HARD (8.8X25.5X2-MM THK) | 1 | |
| 1488315 | 20 CONNECTOR AS | 1 | |
| 2M9780 | SEAL-O-RING | 1 | |
| 6V8642 | CONNECTOR | 1 | |
| 7J9108 | SEAL-O-RING | 1 | |
| 1488341 | 21 CONNECTOR AS | 2 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 6V8713 | CONNECTOR | 1 | |
| 7J9108 | SEAL-O-RING | 1 | |
| 1488378 | 22 ELBOW AS | 2 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V8724 | ELBOW | 1 | |
| 1488390 | 23 ELBOW AS | 1 | |
| 2M9780 | SEAL-O-RING | 1 | |
| 6V8626 | ELBOW | 1 | |
| 7J9108 | SEAL-O-RING | 1 | |
| 2719408 | 24 SCREW-TRUSS HEAD (M5X0.8X10-MM) | 1 | |
| 4B4863 | 25 WASHER (4.7X11X1.2-MM THK) | 4 | |
| 3T0851 | 26 LOCKNUT (M5X0.8-THD) | 2 | |
| 6V8397 | 27 SEAL-O-RING | 1 | |
| 6V8398 | 28 SEAL-O-RING | 8 | |
| 7J9108 | 29 SEAL-O-RING | 3 | |
| 7X2535 | 30 BOLT (M6X1X60-MM) | 2 | |
| 1166952 | 31 BOLT (M4X0.7X10-MM) | 4 | |
| 8T4121 | 32 WASHER-HARD (11X21X2.5-MM THK) | 3 | |
| 8T4137 | 33 BOLT (M10X1.5X20-MM) | 3 | |
| 8T4171 | 34 BOLT (M6X1X12-MM) | 2 | |
| 8T4205 | 35 WASHER-HARD (7.2X14.5X2-MM THK) | 8 | |
| 8T4224 | 36 WASHER-HARD (8.8X16X2-MM THK) | 3 | |
| 8T4908 | 37 BOLT (M8X1.25X25-MM) | 3 | |
| 9R1004 | 38 CLIP (TAB) | 2 | |
| 9R1005 | 39 CLIP (SLOT) | 3 | |
| 9R7802 | 40 CLIP (SLOT) | 1 | |
| 9R7803 | 41 CLIP (TAB) | 1 | |
| 9X2043 | 42 SCREW-TRUSS HEAD (M6X1X14-MM) | 3 | |
| 1989706 | 43 SCREW-TRUSS HEAD (M5X0.8X16-MM) | 2 | |
| 8T0328 | 44 WASHER-HARD (5.5X10X1-MM THK) | 4 | |
| 1129861 | KIT-SEAL | 1 |
