System And Components
332-7664 LINES GP-LIFT CYLINDERS/N TNK1-UP
Group No: 332-7664
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1121817 | 1 VALVE-BALL (LIFT CYLINDER) | 1 | |
| 1908074 | 2 HOSE AS | 2 | |
| 1908075 | 3 HOSE AS | 2 | |
| 2186438 | 4 SEAL | 1 | |
| 2893763 | 5 TUBE AS | 1 | |
| 2893765 | 6 TUBE AS | 1 | |
| 2893766 | 7 TUBE AS | 1 | |
| 3265581 | 8 HOSE AS | 1 | |
| 3265590 | 9 TUBE AS | 1 | |
| 3265612 | 10 HOSE AS | 1 | |
| 3265614 | 11 HANDLE AS | 1 | |
| 3265634 | 12 BRUSH AS | 1 | |
| 3265640 | 13 BRACKET AS | 1 | |
| 1599539 | NUT-WELD (M6X1-THD) | 3 | |
| 1599540 | NUT-WELD (M8X1.25-THD) | 3 | |
| 7X0579 | 14 WASHER-HARD (8.8X25.5X2-MM THK) | 1 | |
| 1488341 | 15 CONNECTOR AS | 2 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 6V8713 | CONNECTOR | 1 | |
| 7J9108 | SEAL-O-RING | 1 | |
| 1488378 | 16 ELBOW AS | 2 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V8724 | ELBOW | 1 | |
| 2719408 | 17 SCREW-TRUSS HEAD (M5X0.8X10-MM) | 1 | |
| 4B4863 | 18 WASHER (4.7X11X1.2-MM THK) | 4 | |
| 3T0851 | 19 LOCKNUT (M5X0.8-THD) | 2 | |
| 6V8398 | 20 SEAL-O-RING | 8 | |
| 7J9108 | 21 SEAL-O-RING | 2 | |
| 1166952 | 22 BOLT (M4X0.7X10-MM) | 4 | |
| 8T4121 | 23 WASHER-HARD (11X21X2.5-MM THK) | 3 | |
| 8T4137 | 24 BOLT (M10X1.5X20-MM) | 3 | |
| 8T4224 | 25 WASHER-HARD (8.8X16X2-MM THK) | 3 | |
| 8T4908 | 26 BOLT (M8X1.25X25-MM) | 3 | |
| 9R1004 | 27 CLIP (TAB) | 2 | |
| 9R1005 | 28 CLIP (SLOT) | 3 | |
| 9R7802 | 29 CLIP (SLOT) | 1 | |
| 9R7803 | 30 CLIP (TAB) | 1 | |
| 9X2043 | 31 SCREW-TRUSS HEAD (M6X1X14-MM) | 3 | |
| 6V8397 | 32 SEAL-O-RING | 1 | |
| 1989706 | 33 SCREW-TRUSS HEAD (M5X0.8X16-MM) | 2 | |
| 8T0328 | 34 WASHER-HARD (5.5X10X1-MM THK) | 4 |
