326-5499 CYLINDER & MTG GP-LIFT ARMS/N YYZ1-UP

Group No: 326-5499
Part NumberPart NameQty
11945941 WASHER (41X64X1-MM THK)10
14287912 PIN AS2
14287933 PIN2
14288324 PIN AS2
19079675 SPACER (38.35X48.35X23.5-MM THK)2
19079796 BOLT (M8X1.25X80-MM)2
19080387 PIN AS2
19195888 PIN AS2
19195899 SUPPORT AS1
191963610 PIN2
191963711 PIN AS2
191963812 PIN AS2
360953913 LINK AS2
191963313A BUSHING2
326538814 PIN AS2
329495315 CYLINDER GP-TILT (RH)1
329495416 CYLINDER GP-TILT (LH)1
329495517 CYLINDER GP-LIFT2
190797118 WASHER-HARD (11X64X6-MM THK)2
2K596419 RING-RETAINING2
3B848820 FITTING-GREASE (1/8-27 PTF)2
3B848921 FITTING-GREASE (1/8-27 PTF)10
4M528522 RING-RETAINING4
5B065123 FITTING-STRAIGHT2
7X051524 WASHER-HARD (17X35X5-MM THK)2
7X059525 WASHER-HARD (17X30X8-MM THK)2
7X772926 WASHER (11X25X3-MM THK)12
8T418627 BOLT (M10X1.5X40-MM)2
8T419128 BOLT (M10X1.5X16-MM)12
8T422429 WASHER-HARD (8.8X16X2-MM THK)2
