System And Components
433-2204 WIRING GP-CABPART OF 433-2203 INSTALLATION GP-ELECTRICAL
Group No: 433-2204
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3E6328 | 1 ALARM GP (24-VOLT) | 1 | |
| 1138490 | 2 FUSE (10-AMPERE) | 1 | |
| 1138491 | 3 FUSE (15-AMPERE) | 2 | |
| 2313930 | 4 RELAY AS (24-VOLT) | 3 | |
| 2578536 | 5 GASKET | 1 | |
| 2705322 | 6 CONTROL GP-VOLTAGE (24-VOLT) | 1 | |
| 2747921 | 7 CONTROL GP-MACHINE (IQAN, XA MODULE) | 1 | |
| 2843659 | 8 SWITCH AS-ROCKER (24-VOLT)(WIPER, WASHER) | 1 | |
| 3521143 | 9 RESISTOR | 1 | |
| 3559440 | 10 CONTROL GP-JOYSTICK | 1 | |
| 3616595 | 11 CONTROL GP-TRANSMISSION | 1 | |
| 3660242 | 12 CONTROL GP-MONITOR (WORK AREA VISUAL SYSTEM) | 1 | |
| 3541827 | CONTROLLER | 1 | |
| 4924591 | SOFTWARE GP-ELECTRONIC | 1 | |
| 3763871 | 13 COVER | 1 | |
| 3774675 | 14 MODULE GP-KEYPAD | 1 | |
| 8F1326 | WASHER (4.2X9.5X0.8-MM THK) | 4 | |
| 8T2659 | LOCKNUT (M4X0.7-THD) | 4 | |
| 4557689 | 15 PLATE AS | 1 | |
| 6V9632 | NUT-WELD (M6X1-THD) | 4 | |
| 3861518 | 16 FILM-INSTRUCTION (JOYSTICK, READ OMM) | 1 | |
| 4520962 | 17 HARNESS AS-CAB | 1 | |
| 4351391 | 18 PLATE AS | 1 | |
| 4351473 | 19 PLATE AS | 1 | |
| 1146658 | 20 WASHER (6.5X17X1-MM THK) | 10 | |
| 1313987 | 21 SCREW (M4X0.7X12-MM) | 4 | |
| 1616984 | 22 SCREW-TRUSS HEAD (M5X0.8X20-MM) | 4 | |
| 1028802 | 23 KIT-RECEPTACLE (2-PIN) | 1 | |
| 3S2093 | 24 STRAP-CABLE | 4 | |
| 4B4274 | 25 WASHER (5.5X13X1.2-MM THK) | 4 | |
| 1728591 | 26 NUT-SPRING (M6X1-THD) | 6 | |
| 7K1181 | 27 STRAP-CABLE | 38 | |
| 8C8585 | 28 SCREW-BUTTON HEAD (M10X1.5X20-MM) | 4 | |
| 8T4138 | 29 BOLT (M6X1X20-MM) | 2 | |
| 9X2038 | 30 WASHER (7X19X2-MM THK) | 7 | |
| 9X2043 | 31 SCREW-TRUSS HEAD (M6X1X14-MM) | 6 | |
| 9X2044 | 32 SCREW-TRUSS HEAD (M6X1X16-MM) | 1 | |
| 9X2045 | 33 SCREW-TRUSS HEAD (M6X1X20-MM) | 10 | |
| 9X8256 | 34 WASHER (6.6X12X2-MM THK) | 2 | |
| 4557690 | 35 PLATE | 1 | |
| 2907164 | 36 FILM-INSTRUCTION (TRANSMISSION SHIFT) | 1 | |
| 1692876 | 37 FILM-IDENTIFICATION (POWER RECEPTACLE, 12-VOLT) | 1 |
