System And Components
377-7206 TANK GP-HYDRAULICPART OF 385-9295 COOLING GP
Group No: 377-7206
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2V2043 | 1 NUT-BULKHEAD (1-5/8-12-THD) | 1 | |
| 7T8331 | 2 MOUNT AS | 8 | |
| 9G5127 | 3 BREATHER (ATMOSPHERIC) | 1 | |
| 1022240 | 4 SENSOR GP-TEMPERATURE (HYDRAULIC OIL) | 1 | |
| 1108827 | 5 FITTING (QUICK DISCONNECT, MALE) | 1 | |
| 2809089 | 6 GUARD AS | 1 | |
| 2809926 | 7 WASHER (32.5X60X5.8-MM THK) | 16 | |
| 8T4136 | 8 BOLT (M10X1.5X25-MM) | 1 | |
| 2855105 | 9 SENSOR GP-LIQUID LEVEL | 1 | |
| 3684371 | 10 PLATE AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 8 | |
| 8T3597 | NUT-WELD (M12X1.75-THD) | 4 | |
| 3708678 | 11 BRACKET AS | 2 | |
| 3708716 | 12 TANK GP-HYDRAULIC | 1 | |
| 3780749 | 13 HOSE AS | 1 | |
| 1223606 | 14 CLIP | 1 | |
| 1240065 | 15 BLOCK | 2 | |
| 1387538 | 16 CONNECTOR | 1 | |
| 1488357 | 17 ELBOW AS | 1 | |
| 6V9008 | ELBOW | 1 | |
| 5K9090 | SEAL-O-RING | 1 | |
| 7M8485 | SEAL-O-RING | 1 | |
| 8T4133 | 18 NUT (M10X1.5-THD) | 14 | |
| 1S0994 | 19 CLIP (LOOP) | 2 | |
| 2M9780 | 20 SEAL-O-RING | 1 | |
| 3K0360 | 21 SEAL-O-RING | 3 | |
| 6V8398 | 22 SEAL-O-RING | 1 | |
| 6V8639 | 23 CONNECTOR | 1 | |
| 6V9746 | 24 SEAL-O-RING | 2 | |
| 7G8839 | 25 SPACER (13.5X57X6-MM THK) | 8 | |
| 7J9108 | 26 SEAL-O-RING | 1 | |
| 7M8485 | 27 SEAL-O-RING | 2 | |
| 8J7844 | 28 ADAPTER | 1 | |
| 8T1685 | 29 TEE | 1 | |
| 8T4121 | 30 WASHER-HARD (11X21X2.5-MM THK) | 40 | |
| 8T4137 | 31 BOLT (M10X1.5X20-MM) | 5 | |
| 8T4195 | 32 BOLT (M10X1.5X30-MM) | 21 | |
| 8T4910 | 33 BOLT (M12X1.75X60-MM) | 8 | |
| 8Y4489 | 34 BOSS (M10X1.5-THD) | 1 | |
| 1305300 | 35 CLIP | 2 | |
| 1325789 | 36 CLIP (LADDER) | 1 | |
| 9L1566 | 37 SUPPORT | 1 | |
| 2826904 | 38 BLOCK | 4 |
