Assembly
100%

455-0424 RADIATOR & HYD OIL COOLER GPS/N E2W1-1499

Group No: 455-0424
Part NumberPart NameQty
3S20931 STRAP-CABLE1
08615072 TANK AS-COOLANT (RECOVERY)1
0861713TANK1
0861714CAP AS-COOLANT TANK (RECOVERY)1
0963288BRACKET1
12552763 CLAMP-HOSE2
8T49834 CLAMP-HOSE2
8T67035 CLAMP-HOSE2
35239646 CLIP (LADDER)1
38829037 BRACKET AS1
6V9632NUT-WELD (M6X1-THD)2
38829118 GUARD AS1
42213129 CLIP1
425296610 HOSE1
425296711 HOSE1
453061012 RADIATOR & HYD OIL COOLER GP1
5P411613 WASHER-HARD (8.8X20.5X2-MM THK)4
5P929914 CLIP (LOOP)2
8T413815 BOLT (M6X1X20-MM)1
8T418916 BOLT (M8X1.25X20-MM)4
8T420517 WASHER-HARD (7.2X14.5X2-MM THK)1
8T422318 WASHER-HARD (13.5X25.5X3-MM THK)4
8T495619 BOLT (M12X1.75X35-MM)4
8T497020 BOLT (M6X1X14-MM)1
9X825621 WASHER (6.6X12X2-MM THK)1
7Y197622 HOSE-WATER (35-CM)
292850423 TUBE (115-CM)
