System And Components
350-1951 PAN GP-OIL -REAR SUMPS/N T4F1-UP
Group No: 350-1951 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3920774 | 1 CONNECTOR AS | 1 | |
| 3E7427 | ADAPTER | 1 | |
| 2792252 | SEAL-O-RING | 1 | |
| 3S2093 | 2 STRAP-CABLE | 1 | |
| 3920775 | 3 PLUG AS-DRAIN (ENGINE OIL PAN) | 1 | |
| 9X6451 | PLUG-DRAIN (MAGNETIC) | 1 | |
| 2792252 | SEAL-O-RING | 1 | |
| 2130677 | 4 SWITCH AS-LIQUID LEVEL (ENGINE OIL) | 1 | |
| 1028802 | KIT-RECEPTACLE (2-PIN) | 1 | |
| 9X3401 | PIN-CONNECTOR (16-GA TO 18-GA) | 2 | |
| 1261767 | PIN-CONNECTOR (14-GA TO 16-GA) | 2 | |
| 2173673 | 5 SEAL-ISOLATION | 1 | |
| 2295331 | 6 PAN-OIL | 1 | |
| 3510283 | 7 VALVE AS-SHUTOFF (ENGINE OIL PAN) | 1 | |
| 6V7238 | VALVE-SHUTOFF (ENGINE OIL PAN) | 1 | |
| 2385080 | SEAL-O-RING | 1 | |
| 2385082 | 8 SEAL-O-RING | 1 | |
| 3503117 | 9 BELL AS-SUCTION | 1 | |
| 2173674 | 11 FASTENER AS | 14 | |
| 2873049 | 12 STUD (M10X1.5X50-MM) | 4 | |
| 3196234 | 13 PLUG AS | 2 | |
| 9S9334 | PLUG (1-5/16-12-THD) | 1 | |
| 2385084 | SEAL-O-RING | 1 | |
| 3E8016 | 14 BOLT-SELF-LOCKING (M8X1.25X25-MM) | 2 | |
| 5P8211 | 15 SEAL-O-RING | 1 | |
| 5P8245 | 16 WASHER-HARD (13.5X25.5X3-MM THK) | 4 | |
| 6A5591 | 17 BOLT (M12X1.75X25-MM) | 4 | |
| 6N8863 | 18 WASHER (10.2X32X2.5-MM THK) | 14 | |
| 6V4249 | 19 BOLT (M10X1.5X50-MM) | 10 | |
| 9M1974 | 20 WASHER-HARD (8.8X16X2-MM THK) | 2 |
