System And Components
342-6224 LINES GP-WATER -EXHAUST COOLERS/N T4F1-UP
Group No: 342-6224 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2627221 | 1 TUBE | 1 | |
| 4374425 | 2 SEAL-O-RING | 2 | |
| 3349855 | 3 ELBOW | 1 | |
| 4533363 | 4 BRACKET AS | 1 | |
| 8T3612 | NUT-WELD (M8X1.25-THD) | 1 | |
| 3514607 | 5 ELBOW | 1 | |
| 3514608 | 6 TUBE | 1 | |
| 3532898 | 7 ELBOW | 1 | |
| 3048008 | 8 PLUG AS | 1 | |
| 6V9027 | SEAL-O-RING | 1 | |
| 9S8002 | PLUG (7/16-20-THD) | 1 | |
| 6V2315 | 9 BOLT (M6X1X35-MM) | 2 | |
| 6V2317 | 10 BOLT (M8X1.25X30-MM) | 2 | |
| 6V5217 | 11 BOLT (M8X1.25X20-MM) | 1 | |
| 6V7728 | 12 BOLT (M6X1X45-MM) | 2 | |
| 6V8836 | 13 BOLT (M6X1X14-MM) | 1 | |
| 7L6580 | 14 SEAL-O-RING | 4 | |
| 8S0023 | 15 CLIP (SLOT) | 1 | |
| 8S0024 | 16 CLIP (TAB) | 1 | |
| 8T5917 | 17 SEAL-O-RING | 1 | |
| 9M1974 | 18 WASHER-HARD (8.8X16X2-MM THK) | 2 | |
| 9N0869 | 19 WASHER-HARD (8.8X25.5X2-MM THK) | 1 | |
| 9X8267 | 20 WASHER (6.6X12X2-MM THK) | 5 |
