System And Components
348-3043 LINES GP-WATERS/N T4F1-636
Group No: 348-3043 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2888580 | 1 CLAMP-FUEL LINE | 2 | |
| 3447465 | 2 PLATE-SUPPORT | 1 | |
| 3483044 | 3 HOSE AS | 1 | |
| 3483045 | 4 TUBE AS | 1 | |
| 3483046 | 5 TUBE AS | 1 | |
| 3499941 | 6 PLATE AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 1 | |
| 0974896 | 7 SPACER (12X20X23-MM THK) | 1 | |
| 1387500 | 8 SPACER (11X25X50-MM THK) | 1 | |
| 1448344 | 9 SPACER (11X19X20-MM THK) | 1 | |
| 2147568 | 10 SEAL-O-RING | 1 | |
| 2287088 | 11 SEAL-O-RING | 7 | |
| 2287089 | 12 SEAL-O-RING | 1 | |
| 2385081 | 13 SEAL-O-RING | 1 | |
| 2P1279 | 14 LOCKNUT (9/16-18-THD) | 2 | |
| 3422134 | 15 CLIP | 3 | |
| 3453350 | 16 CLIP | 1 | |
| 6V5217 | 17 BOLT (M8X1.25X20-MM) | 2 | |
| 6V5219 | 18 BOLT (M8X1.25X40-MM) | 1 | |
| 6V5839 | 19 WASHER (11X21X2.5-MM THK) | 3 | |
| 6V5842 | 20 BOLT (M10X1.5X40-MM) | 1 | |
| 6V6317 | 21 BOLT (M10X1.5X20-MM) | 1 | |
| 6V7981 | 22 BOLT (M10X1.5X70-MM) | 1 | |
| 6V8214 | 23 BOLT (M6X1X20-MM) | 1 | |
| 6V8225 | 24 NUT (M6X1-THD) | 1 | |
| 6V8627 | 25 ELBOW | 1 | |
| 6V8934 | 26 ADAPTER | 1 | |
| 6V8993 | 27 UNION | 2 | |
| 9X8267 | 28 WASHER (6.6X12X2-MM THK) | 1 | |
| 9M1974 | 29 WASHER-HARD (8.8X16X2-MM THK) | 3 | |
| 9X2134 | 30 ELBOW | 1 |
