System And Components
498-1139 LINES GP-WATERS/N T4F1-UP
Group No: 498-1139 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2627221 | 1 TUBE | 1 | |
| 2893107 | 2 GASKET | 1 | |
| 3048008 | 3 PLUG AS | 1 | |
| 6V9027 | SEAL-O-RING | 1 | |
| 9S8002 | PLUG (7/16-20-THD) | 1 | |
| 3532898 | 4 ELBOW | 1 | |
| 4374425 | 5 SEAL-O-RING | 1 | |
| 4533363 | 6 BRACKET AS | 1 | |
| 8T3612 | NUT-WELD (M8X1.25-THD) | 1 | |
| 4875075 | 7 ELBOW | 1 | |
| 5170055 | 8 TUBE AS-WATER | 1 | |
| 6V2317 | 9 BOLT (M8X1.25X30-MM) | 2 | |
| 6V5217 | 10 BOLT (M8X1.25X20-MM) | 1 | |
| 6V7728 | 11 BOLT (M6X1X45-MM) | 2 | |
| 6V8836 | 12 BOLT (M6X1X14-MM) | 1 | |
| 7L6580 | 13 SEAL-O-RING | 3 | |
| 8S0023 | 14 CLIP (SLOT) | 1 | |
| 8S0024 | 15 CLIP (TAB) | 1 | |
| 8T4971 | 16 BOLT (M6X1X30-MM) | 2 | |
| 8T5917 | 17 SEAL-O-RING | 1 | |
| 9M1974 | 18 WASHER-HARD (8.8X16X2-MM THK) | 2 | |
| 9N0869 | 19 WASHER-HARD (8.8X25.5X2-MM THK) | 1 | |
| 9X8256 | 20 WASHER (6.6X12X2-MM THK) | 2 | |
| 9X8267 | 21 WASHER (6.6X12X2-MM THK) | 3 |
