System And Components
351-2424 SHROUD GP-RADIATORS/N NDC1-UP; YEG1-UP; A9J1-UP
Group No: 351-2424 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3354180 | 1 CLAMP | 1 | |
| 3365598 | 2 SEAL | 1 | |
| 3512423 | 3 SHROUD-FAN | 1 | |
| 3529424 | 4 BRACKET-SUPPORT | 1 | |
| 3529425 | 5 BRACKET-SUPPORT | 1 | |
| 3529426 | 6 BRACKET-SUPPORT | 1 | |
| 3529427 | 7 BRACKET-SUPPORT | 1 | |
| 7X7729 | 8 WASHER (11X25X3-MM THK) | 6 | |
| 8T4121 | 9 WASHER-HARD (11X21X2.5-MM THK) | 12 | |
| 8T4136 | 10 BOLT (M10X1.5X25-MM) | 6 | |
| 8T4196 | 11 BOLT (M10X1.5X35-MM) | 6 | |
| 8T6466 | 12 BOLT (M10X1.5X60-MM) | 6 |
