System And Components
235-7133 ALTERNATOR GP-CHARGINGS/N T4F1-17319
Group No: 235-7133 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2289656 | 1 FRAME AS-DRIVE END | 1 | |
| 5S7349 | 2 BOLT (1/4-20X0.5-IN) | 1 | |
| 1852639 | 3 FAN AS | 1 | |
| 1H3244 | 4 LOCKWASHER | 1 | |
| 2289655 | 5 FRAME AS-ALTERNATOR | 1 | |
| 2K4821 | 6 LOCKNUT (5/8-18-THD) | 1 | |
| 5P8247 | 7 WASHER-HARD (17X32X3.5-MM THK) | 1 | |
| 2289657 | 8 COVER AS | 1 | |
| 8T4205 | 9 WASHER-HARD (7.2X14.5X2-MM THK) | 1 | |
| 1852647 | 10 GROMMET | 1 | |
| 9L6770 | 11 CAP-DUST | 1 | |
| 4232775 | 12 STATOR AS (24-VOLT, 95-AMPERE) | 1 | |
| 1852638 | 13 COLLAR | 2 | |
| 1852654 | 14 PLATE | 1 | |
| 1852650 | 15 ROTOR AS | 1 | |
| 1852644 | 16 COIL AS | 1 | |
| 1852648 | 17 REGULATOR AS-VOLTAGE (24-VOLT)(ALTERNATOR) | 1 | |
| 6V8189 | 18 NUT (5/16-18-THD) | 1 | |
| 8T4224 | 19 WASHER-HARD (8.8X16X2-MM THK) | 1 | |
| 3F9556 | 20 LOCKWASHER | 1 | |
| 1852655 | KIT-BEARING (ALTERNATOR) | 1 | |
| 1852658 | KIT-HARDWARE (ALTERNATOR AIR) | 1 | |
| 1997891 | KIT-TERMINAL (ALTERNATOR AIR) | 1 | |
| 1998436 | KIT-TERMINAL (ALTERNATOR AIR) | 1 |
