System And Components
377-8286 LIGHTING GP-FLOOD -BOOMS/N YEG1-UP; A9J1-UP
Group No: 377-8286 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1114836 | 1 CLIP | 13 | |
| 1114837 | 2 CLIP | 1 | |
| 1160118 | 3 CLIP | 1 | |
| 3346198 | 4 LAMP GP-FLOOD (24-VOLT, 35-WATT, HID)(BOOM, LH) | 1 | |
| 3346198 | 4A LAMP GP-FLOOD (24-VOLT, 35-WATT, HID)(BOOM, RH) | 1 | |
| 3508186 | 5 BRACKET | 2 | |
| 3886721 | 6 HARNESS AS-LIGHTING (BOOM) | 1 | |
| 9W0852 | PIN-CONNECTOR (14-GA TO 16-GA) | 2 | |
| 9W0844 | SOCKET-CONNECTOR (14-GA TO 16-GA) | 4 | |
| 1257875 | TUBE-HEAT SHRINK (7.44-MM DIA)(10-CM) | ||
| 1552270 | KIT-CONNECTING PLUG (2-PIN) | 2 | |
| 2434505 | RECEPTACLE AS-CONNECTOR (2-PIN) | 1 | |
| 6V3265 | 7 CLIP | 2 | |
| 7I2673 | 8 STRAP-CABLE | 2 | |
| 4532834 | 9 BOLT (M16X2X30-MM) | 2 | |
| 8T4121 | 10 WASHER-HARD (11X21X2.5-MM THK) | 3 | |
| 8T4133 | 11 NUT (M10X1.5-THD) | 3 | |
| 4512175 | 12 WASHER-HARD (17.5X30X3.5-MM THK) | 2 | |
| 8T4223 | 13 WASHER-HARD (13.5X25.5X3-MM THK) | 11 | |
| 1757141 | 14 NUT-HEX FLANGE (M10X1.5-THD) | 14 |
