System And Components
396-1789 PANEL GP-CIRCUIT BREAKERS/N NDC1-UP; YEG1-UP; A9J1-UP
Group No: 396-1789 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3993433 | 1 GROMMET | 1 | |
| 3993443 | 2 BAR-BUS | 1 | |
| 3995257 | 3 BAR-BUS | 1 | |
| 1712205 | 4 CIRCUIT BREAKER AS (40-AMPERE)(DOSING CONTROL UNIT) | 1 | |
| 1712211 | 5 CIRCUIT BREAKER AS (90-AMPERE)(ALTERNATOR) | 1 | |
| 1712212 | 6 CIRCUIT BREAKER AS (105-AMPERE)(MAIN) | 1 | |
| 4E5724 | WASHER (7X12X1-MM THK) | 2 | |
| 8T0122 | NUT-FULL (1/4-28-THD) | 2 | |
| 1H3244 | LOCKWASHER | 2 | |
| 3993431 | 7 BRACKET AS | 1 | |
| 1211029 | CLIP | 1 | |
| 3993434 | 8 BLOCK AS-TERMINAL | 1 | |
| 3B4504 | LOCKWASHER | 8 | |
| 8T4171 | BOLT (M6X1X12-MM) | 4 | |
| 8T6411 | SCREW-MACHINE (M6X1X12-MM) | 4 | |
| 9X8256 | WASHER (6.6X12X2-MM THK) | 8 | |
| 3993435 | 9 BLOCK GP-JUNCTION | 1 | |
| 3993436 | 10 WIRE AS | 1 | |
| 3993438 | 11 BAR-BUS | 1 | |
| 4B2049 | 12 NUT (10-32-THD) | 2 | |
| 5A4631 | 13 WASHER (5.5X12X0.8-MM THK) | 6 | |
| 6V5645 | 14 SCREW-MACHINE (10-32X0.87-IN) | 8 | |
| 8T4127 | 15 SCREW-MACHINE (M5X0.8X20-MM) | 4 |
