System And Components
327-7478 SENSOR & MTG GP-POSITION -GRADE CONTROL, STICKPART OF 344-0819, 527-7133 BOOM AR-REACH
Group No: 327-7478 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1448073 | 1 LOCKWASHER | 1 | |
| 3095695 | 2 ROD AS | 1 | |
| 8T4133 | NUT (M10X1.5-THD) | 1 | |
| 9X2065 | NUT (M10X1.5-THD, LH) | 1 | |
| 4629427 | 3 LEVER AS | 1 | |
| 3451948 | 4 SENSOR GP-POSITION (ROTARY)(GRADE CONTROL, STICK) | 1 | |
| 3495427 | 5 SPACER | 1 | |
| 4616640 | 6 PLATE AS | 1 | |
| 3495542 | 7 HOLDER | 1 | |
| 1053487 | 8 BOLT-SOCKET HEAD (M6X1X20-MM) | 1 | |
| 1313983 | 9 BOLT-SOCKET HEAD (M8X1.25X35-MM) | 4 | |
| 5C9553 | 10 BOLT (M6X1X16-MM) | 2 | |
| 8T4121 | 11 WASHER-HARD (11X21X2.5-MM THK) | 4 | |
| 8T4196 | 12 BOLT (M10X1.5X35-MM) | 1 | |
| 8T4224 | 13 WASHER-HARD (8.8X16X2-MM THK) | 4 | |
| 9X2039 | 14 SCREW-TRUSS HEAD (M10X1.5X35-MM) | 1 | |
| 9X8256 | 15 WASHER (6.6X12X2-MM THK) | 2 |
