Assembly
100%

524-0532 SENSOR & MTG GP-POSITIONS/N NDC10001-UP; YEG10001-UP; A9J10001-UP

Group No: 524-0532 · Commonality
Part NumberPart NameQty
31207551 SENSOR AS-ANGLE (BODY TILT)1
4936777SOFTWARE GP-MONITOR (ANGLE SENSOR)1
52405332 BRACKET AS1
8T41393 BOLT (M12X1.75X30-MM)2
8T42004 BOLT (M8X1.25X16-MM)4
8T42235 WASHER-HARD (13.5X25.5X3-MM THK)2
8T42246 WASHER-HARD (8.8X16X2-MM THK)4
