System And Components
524-2234 SENSOR & MTG GP-POSITION -BUCKETS/N NDC20001-UP; YEG20001-UP; A9J20001-UP
Group No: 524-2234 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3S2093 | 1 STRAP-CABLE | 4 | |
| 4784873 | 2 SENSOR-POSITION (BUCKET) | 1 | |
| 4784876 | 3 SENSOR GP-POSITION (BUCKET) | 1 | |
| 5066195 | 4 COVER AS | 1 | |
| 1364192 | 5 BOLT (M6X1X35-MM) | 5 | |
| 8T4121 | 6 WASHER-HARD (11X21X2.5-MM THK) | 4 | |
| 8T4137 | 7 BOLT (M10X1.5X20-MM) | 3 | |
| 8T4189 | 8 BOLT (M8X1.25X20-MM) | 3 | |
| 8T4196 | 9 BOLT (M10X1.5X35-MM) | 1 | |
| 8T4222 | 10 WASHER-PLATED (11X32X2.5-MM THK) | 4 | |
| 8T4224 | 11 WASHER-HARD (8.8X16X2-MM THK) | 3 | |
| 9X8256 | 12 WASHER (6.6X12X2-MM THK) | 5 | |
| 3E6600 | 13 SEAL (1.5-CM EACH) |
