System And Components
345-3846 SENSOR GP-ENGINES/N T4F1-154
Group No: 345-3846 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3S2093 | 1 STRAP-CABLE | 5 | |
| 1781781 | 2 CLIP | 1 | |
| 2345012 | 3 SENSOR GP-TEMPERATURE (COOLANT) | 1 | |
| 2345013 | 4 SENSOR GP-TEMPERATURE (OUTLET AIR) | 1 | |
| 2861238 | 5 BRACKET | 1 | |
| 2935535 | 6 SENSOR GP-PRESSURE (3-PIN)(ENGINE OIL) | 1 | |
| 2946119 | 7 SENSOR GP-PRESSURE (CRANKCASE BREATHER) | 1 | |
| 3841836 | 8 SENSOR GP-SPEED (PRIMARY, TIMING) | 1 | |
| 3009806 | 9 SENSOR GP-SPEED (SECONDARY, TIMING) | 1 | |
| 3309740 | 10 ADAPTER AS | 1 | |
| 2147566 | SEAL-O-RING | 1 | |
| 3309739 | ADAPTER | 1 | |
| 3311134 | 11 SENSOR GP-PRESSURE (ATMOSPHERIC) | 1 | |
| 3311135 | 12 SENSOR GP-PRESSURE (INTAKE AIR MANIFOLD) | 1 | |
| 4434151 | 13 BRACKET | 1 | |
| 3320296 | 14 SENSOR GP-PRESSURE (NRS ABSOLUTE) | 1 | |
| 4743231 | 15 SENSOR AS-TEMPERATURE (2-PIN)(NOX REDUCTION SYSTEM) | 1 | |
| 2818802 | RECEPTACLE AS-CONNECTOR (2-PIN) | 1 | |
| 3851173 | 16 SENSOR GP-PRESSURE (NOX REDUCTION SYSTEM) | 1 | |
| 1091393 | 17 BOLT-SOCKET HEAD (M4X0.7X10-MM) | 4 | |
| 1378101 | 18 SEAL-O-RING | 2 | |
| 1833407 | 20 PLUG AS | 1 | |
| 9S8004 | PLUG (9/16-18-THD) | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 2Y5829 | 21 NUT (M10X1.5-THD) | 1 | |
| 2856395 | 22 CLIP (LADDER) | 1 | |
| 6V5215 | 23 BOLT (M8X1.25X16-MM) | 2 | |
| 6V3940 | 25 BOLT (M8X1.25X25-MM) | 3 | |
| 8T4970 | 26 BOLT (M6X1X14-MM) | 1 | |
| 9M1974 | 27 WASHER-HARD (8.8X16X2-MM THK) | 3 | |
| 3072673 | 28 PLUG AS | 1 | |
| 9S8005 | PLUG (3/4-16-THD) | 1 | |
| 2385080 | SEAL-O-RING | 1 | |
| 9X6165 | 29 WASHER (6.5X22X2.5-MM THK) | 1 | |
| 7W9094 | 30 SPACER (11X20X9-MM THK) | 1 | |
| 4218565 | 31 BRACKET | 1 |
